BASSBOSS BB15 Single 15″ Powered Subwoofer

The SMALL, CUTE+ LOUD

Petite cabinet, big booty! The BB15 brings the bass, takes up no space. The BB15 subwoofer’s compact size and excellent output-to-price ratio was designed for gigging DJs, home studio bass-heads, or venue owners with limited space.

PORTABLE POWER

For DJs and venues seeking extremely deep bass at moderately high levels in tight spaces, the BB15 is the smallest, lightest and most cost-effective solution available. Suitable for the truly bass-insatiable, whose focus is on modern music that features frequencies from 40-50Hz at up to 130dB, this extremely compact sub weighs only 70 lbs.

DESIGN

The BB15 is a single 15-inch direct-radiating subwoofer. Featuring a long excursion, 15-inch woofer loaded into a vented enclosure that is tuned to optimize low frequency output using a very large port. The amplifier is loaded at the interior port end to utilize the air flow at high output for additional cooling. The cabinet was designed to minimize materials, cost and weight and maximize efficiency.

POWER

It includes a 2400W RMS amplifier, rated for RMS output using continuous sine wave signal. This is not a peak or burst power rating. The amplifier is capable of delivering 2400W of continuous output, ensuring that the amp isn’t the limiting factor in the output of low frequencies. Providing abundant power also virtually eliminates the possibility of overheating and damage to the woofers caused by clipping.

A game changer

The BB15s sound amazing. I was able to fill a giant ball room with sound and bass with two DV12s and two BB15s. Plus they’re easy to carry. I had people at the hotel complaining my system was too loud at just 12′ O’clock while playing cocktail music. This other DJ in the room at the other end had 3 carts of equipment and I only had one, and my system was louder than his. The BB15s are a mobile DJ’s dream, a game changer.

DRIVER

All that electrical power is converted into acoustical power by a 15-inch neodymium motor woofer. This premium quality driver features a copper-winding voice coil. High-intensity Neodymium magnets are lighter and provide higher efficiency so the result is a lighter and louder cabinet.

PROCESSING

Integrated, comprehensive DSP is included. Processing includes high-pass and low-pass filters as well as multiple protection systems and limiters to control all manners of driver overload, including thermal, excursion and clipping. The protection systems effectively prevent overheating of the voice coils and minimize long-term thermal compression while having virtually no effect on the transient response and peak output of the loudspeaker.

Product Specifications:

Loudspeaker Description: Single 15” direct-radiating vented subwoofer

Frequency Response (±3 dB): 40-105Hz

Maximum Sustained Output: 127 dB SPL, 1-meter, half-space (ground plane)

Max SPL (Peak): 130 dB

Nominal Dispersion (H° x V°): Omnidirectional (360 x 360)

Amplification: 2400-Watt Continuous RMS Class D Subwoofer Amplifier

Processing: Integrated Comprehensive DSP including High Pass, Low Pass, Phase Alignment, EQ and Limiting

Enclosure Type:  CNC machined 15mm multi-ply Birch laminate with extensive bracing and dado joinery.

Transducer: 1 x 15 in. diameter (380mm) Neodymium motor woofer with 4 in. (100mm) voice coil, waterproof cone

Cabinet Construction: 18 mm Baltic Birch plywood. Equipped with 2 integrated handles, 1 pole socket, and 4 rubber feet

Dimensions (HxWxD): 20.5 in (521mm) x17 in (430mm) x 24 in (610mm) (21.25 in. high with feet)

Net Weight: 70 lbs

Shipping Weight: 83 lbs
