Description
The Bose MA12 is a Panaray Modular Line Array Loudspeaker. Wide 145° horizontal coverage. Designed to provide outstanding vocal intelligibility in acoustically demanding spaces. Slim column enclosure blends with almost any décor.
Twelve 2.25" (64 mm)
Drivers mounted in a vertical line array deliver wide horizontal coverage with narrow vertical pattern control.
Modular Design
Allows stacking of multiple enclosures in a line array configuration to provide increased vertical pattern control which improves “throw” distance and reduces unwanted floor/ceiling reflections.
145° Horizontal X 20° Nominal Coverage
Coverage for a single module. Vertical coverage varies with the number of modules stacked in the line array configuration.
Mid/High Configuration
Allows bass management and design flexibility. Use with Bose MB4, MB12, or MB24 modular bass loudspeakers for full-range reinforcement.
Optional Brackets
Allow easy installation of single-, double- or triple-stack line array modules.
Applications:
Houses of worship
Multi-purpose spaces
Recreation
Restaurants and bars
Auditoriums
Transportation facilities
Gymnasiums
Atriums and malls
Product Specifications
| Specification | Details |
|---|---|
| Frequency Response (+/-3 dB) | 155 Hz - 12 kHz |
| Frequency Range (-10 dB) | 100 Hz - 16 kHz |
| Nominal Dispersion | 145° H x 20° V |
| Long-Term Power Handling | 300 W (1200 W peak) |
| Sensitivity (SPL / 1 W @ 1 m) | 88 dB SPL |
| Maximum SPL @ 1 m | 113 dB SPL (119 dB SPL peak) |
| Nominal Impedance | 8 Ω |
