Elation Sniper 2R Multi Effect Luminaire Hybrid Effects Processor

The Elation Sniper 2R Multi Effect Luminaire Hybrid Effects Processor is a revolutionary new hybrid effects projector, scanner and laser simulator which features new lamp technology, the MSD Platinum 2R Lamp at 132 Watts / 6,000 hours. Capable of producing powerful and precise beam and laser like effects - including liquid sky, laser wave and cones, all moving at speeds never seen before. The Sniper 2R™ main functions include a X / Y scan and Z rotation mirror system, 3 facet rotating prism, variable speed shutter / dimmer / strobe, 14 dichroic colors, 17 static gobos including beam reduction gobos, 5pin DMX and powerCON in/out connections, (4) button control panel, 220W max power consumption, and a multi-voltage universal auto switching power supply (120-240v).

Product Specification:

Source

132W Platinum 2R Lamp

6,000 Hour Average Life

Photometric Data

Measured with 3° Beam Full On

45,010 LUX 4,181 FC @16.4’ (5m)

12,050 LUX 1,119 FC @32.8’ (10m)

5,633 LUX 523 FC @49.2’ (15m)

3,178 LUX 295 FC @65.6’ (20m)

2,276 LUX 212 FC @82.0’ (25m)

Effects

Strobe

Electronic Dimmer

3 Facet Rotating Prism

Multiple Pattern Macros

Color

(14) Dichroic Colors + White

Gobos

(17) Gobos + Open

Control / Connections

(3) DMX Channel Modes (14 / 16 / 18)

4 Button Control Panel

5pin DMX in/Out

powerCON in/Out

Size / Weight

Length: 14.2” (361mm)

Width: 12.0” (305mm)

Vertical Height: 11.6” (295mm)

Weight: 21.0 lbs. (9.5 kg)

Electrical / Thermal

AC 100-240V - 50/60Hz

220W Max Power Consumption

Multiple Unit Power Linking (max 7 @120V / 14 @230V)

104°F (40°C) Max Ambient Temperature

Approvals / Ratings

CE | cETLus | IP20

Installation

Rigging: Clamps (Not Included)

Working Position: Any (360°)

Included Items

(1) Adjustable Mounting Yoke

(1) powerCON Cable
