Description
The Neumann KH 750 AES67 Compact DSP-Controlled Closed-Cabinet Subwoofer is the ideal for routing audio over IP in an existing AES67 studio infrastructure all the way to the loudspeakers in a redundant and lossless manner. It thus serves as the link between the studio’s digital ST2110/AES67 data stream and all KH line monitors.
By adding more KH 750 AES67 subwoofers, stereo systems of any size can be realized. The KH 750 AES67 adds AES67 connectivity and retains all other features of the KH 750 DSP such as the unique and flexible Bass Manager as well as analog and digital inputs, four routing modes, and adaptable acoustical controls to be used in many different configurations and setups.
The KH 750 AES67 model variant offers newly integrated redundant AES67 audio network ports that are fully compliant with broadcast standards such as ST 2110 and ST 2022-7 redundancy. At the same time, the KH 750 AES67 is compatible with DANTE-generated AES67 network streams. The KH 750 AES67 thus enables all pairs of KH line monitors to be integrated into a redundant AES67 IP network.
Product Specifications
Monitor Type & Configuration: Active Subwoofer
Enclosure: Sealed, Shielded
Total Power Output: 256 W
Drivers: LF: 1 x 10" / 25.4 cm Woofer
Frequency Range: 18 Hz to 750 Hz ± 3 dB
Frequency Response: 18 Hz to 800 Hz ± 6 dB
Maximum Sound Pressure Level (SPL): 105 dB
Dynamic Range: 119 dBA
Filters: 1 x Low-Pass
Crossover Frequency: 80 Hz, 24 dB/Octave Slope
Crossover Type: Active
Phase Adjustment: 0 / 180° Phase Inversion, 4-Position Switch
Maximum Sampling Rate: 96 kHz / 24-Bit
USB & Network I/O: 2 x RJ45 (AES67, Controller, Network)
AC Input Power: 100 to 240 VAC, 50/60 Hz
Power Consumption: 410 W (Maximum)
Enclosure Material: Aluminum, Wood
Operating Temperature: 50 to 104°F / 10 to 40°C
Operating Humidity: 90%
Storage Temperature: -13 to 158°F / -25 to 70°C
Dimensions (W x H x D): 13 x 15.1 x 15.1" / 33 x 38.3 x 38.3 cm
Weight: 43 lb
Package Weight: 50 lbs
Box Dimensions (LxWxH): 21 x 19 x 16"
