Tannoy PCI Sub IW with Back Can Premium Dual 8-Inch Wall Subwoofer

The Tannoy Pci Sub IW With Back Can Premium Dual 8 In-Wall Subwoofer is Designed to fit seamlessly into your world, the new Tannoy PCI series is the perfect premium loudspeaker for modern living. Discover a beautiful blend of innovative technology combined with sophisticated good looks that will match any décor. State of the art driver materials and Tannoy’s Unique Dual Concentric driver technology combine to deliver music and film that is breathtakingly realistic and with phenomenal clarity. The PCI Range is designed with the same exacting standards as our flagship hi-fi and professional loudspeakers. Unlike other loudspeakers brands, Tannoy has a unique history of technological development and craftmanship.

During every step of the creative process from composition to recording, mixing and mastering to broadcast, artists around the world trust Tannoy loudspeakers to faithfully reproduce every music nuance with stunning accuracy. Audiophile’s trust Tannoy loudspeakers to authentically reproduce music exactly as the artist intended, with true to source accuracy and a design elegance that is equally pleasing to the ears and eyes. Carefully considered aesthetics, state of the art materials, quality and craftmanship seamlessly blend to create loudspeakers that will deliver reference sound to be enjoyed for many years to come.

Dual Woofer

Designed and engineered in the UK, this dedicated sub-woofer handles up to 800 Watts and is extremely easy to drive. The compact, stylish and state of the art design comprises dual 200mm (8.00") LF drivers with high-excursion rubber surround. The dual-driver configuration offers increased cone surface area for exceptional punch and low-frequency extension from a compact and highly efficient design. The dual drivers provide a similar surface area to a much larger single 400mm (16.00”) driver. This elegant solution has the added benefit of being lighter and quicker to respond to all important musical transients, delivering the performance of a large cabinet subwoofer without sacrificing floor space. Low-frequency performance is full and impactful, with clean, clear and dynamic bass. These characteristics make this dual-driver design perfect for premium audio listening. The PCI SUB IW is ideal for small, medium and large-sized rooms.

Elegant Simplicity

Engineered to the highest standard the PCI range feature powder-coated perforated UV resistant steel mesh grills that protect from dust and can be removed and painted to match any décor. The PCI Sub IW has an extremely thin bezel for unobtrusive installation. Optimised to maximise performance a wooden pre-install back can kit is included.

Product Specifications:

Frequency Response (±3 Db): 100 Hz – 2 Khz

Frequency Response (-10 Db): 45 Hz – 2.3 Khz

Sensitivity (1 W @ 1m): 90 Db

Power Handling (IEC):

Average: 200 W

Programme: 400 W

Peak: 800 W

Recommended Amplifier Power: 600 W @ 8 Ω

Nominal Impedance (Lo Z): 8 Ω

Rated Maximum SPL (1 M, Lo Z) : 116 Db

Average: 113 Db

Peak: 119 Db

Crossover Point: NA

Transducers: Low Frequency Diameter/Material/Type 2 X 219 Mm (8")

Physical:

Back Can: BACK CAN PCI SUB IW Wood

Baffle: Reflex Loaded UL94 V-0 Rated ABS

Grille: Steel, With Weather Resistant Coating

Clamping Design: Security Toggle Clamp

Connectors: Phoenix Contact Terminal Block

Dimensions: (H X W X D): 1465 X 345 X 113 Mm (57.7 X 13.6 X 4.5")

Bezel Dimensions: 495.6 X 264.5 Mm (19.5 X 10.4")

Mounting Depth: 93.1 Mm (3.7")

Hole Cut-Out Dimensions: 482,5 X 252,5 Mm (19 X 9.94")

Net Weight: 16.9 Kg (37.2 Lbs)

Included Accessories:

PCI SUB IW: Grille, Paint Mask, Cut-Out Template.

BACK CAN PCI SUB IW: Washers (X12), Screws (X12), Bracket (X4), Cable Clamp.

Optional Accessories: PCI SUB IW And Back Can PCI SUB IW Be Also Available Separately

Shipping Dimensions (HxWxD): (58 X 14 X 5")

Shipping Weight: (39 Lbs)
