The Tannoy VX 12Q-WH 12 Inches Power Dual Full Range Loudspeaker with Q-Centric Waveguide – White is a new class of device that delivers high SPL, low distortion audio coverage in a complete high-performance loudspeaker cabinet. It provides a high impact solution for medium to-large scale sound reinforcement in high-SPL applications such as bars and clubs, as well as being well suited for mid-scale portable/live PA applications. Thanks to its twin driver design for extended low frequency reproduction and flexible mounting options, the VX 12Q-WH is also ideally suited for use complimenting much larger systems, making it an excellent choice for both installed and portable applications. The VX 12Q-WH can also be configured for bi-amp operation.
Power Dual Driver
The 1,400-Watt 305 mm (12") version of TANNOY’s VX Series exclusive point source loudspeakers, VX 12Q-WH’s Power Dual driver ensures high power output with high sensitivity and exceptional efficiency. A proprietary Q-Centric waveguide is provided for tighter pattern control, delivering precise 75º horizontal x 40º vertical dispersion for optimum coverage, exceptional forward gain plus the added benefit of improved low-mid extension from the twin driver configuration.
VX 12Q-WH’s trapezoidal enclosure design provides a multitude of placement options including: installed performance sound reinforcement, FOH, floor monitor, high SPL delay, and more. A blanking plate for optional VTH pole mounting is provided for placement atop a subwoofer in portable PA applications. Mounting options include horizontal and vertical mounting yokes (available separately), and 8 M10 Flying inserts. All hardware has been tested and certified for a greater than 5:1 safety ratio giving installers complete peace of mind.
Finished in a hard wearing semi matt black paint, the vented and internally braced cabinet is constructed from a combination of 15 mm (⅝") and 18 mm (¾") plywood – and includes a rugged powder coated perforated steel mesh grille. Integrip handles ergonomically integrated into the top and bottom of cabinet make for easy transport. The rear panel connector plate carries Neutrik speak ON NL4 and barrier strip connectors for input and link connections to additional enclosures
|Frequency Response (-3 dB) 1)||80 Hz - 25 Hz|
|Frequency Range (-10 dB) 1||60 Hz - 30 kHz|
|System Sensitivity: (1 W @1 m) 2)||- Passive - Full Range: 97 dB (1W = 2.83 V for 8 ohms)<br> - Biamp (LF): 98 dB<br> - Biamp (HF): 108 dB|
|Dispersion (degrees conical)||75 degrees (H) x 40 degrees (V)|
|Driver Complement||1 x 305 mm (12.00") Power Dual with Q-Centric waveguide.|
|Crossover||Passive 1.5 kHz (Product can be reconfigured for bi-amped operation. Bi-amp system parameters in Operation Manual.)|
|Directivity Factor (Q)||13.0 (averaged 1 kHz to 8 kHz)|
|Directivity Index (DI)||11.1 (averaged 1 kHz to 8 kHz)|
|Power Handling||- Passive - Full Range: Average: 350 W, Programmed: 700 W, Peak: 1400 W<br> - Biamp (LF): Average: 350 W, Programmed: 700 W, Peak: 1400 W<br> - Biamp (HF): Average: 80 W, Programmed: 160 W, Peak: 320 W|
|Dimensions (H x W x D)||W: 370 mm (14.6"), H: 486 mm (19.1"), D: 360 mm (14.1")|
|Net Weight||21.0 kg (46.3 lbs)|
