Descripción

The Blizzard Lighting Armor A5s Plus is a compact LED display receiving card designed to provide reliable data processing and advanced image control for LED display systems. A single card supports up to 512 x 384 pixels for 8-bit video sources when used with supported PWM driver ICs. It also supports up to 32 groups of parallel RGB data and 64 groups of serial data, providing flexible connectivity for a wide range of LED display configurations.

The A5s Plus features 18bit+ processing, color management, and pixel-level brightness and chroma calibration to improve grayscale performance, color accuracy, and overall display uniformity. Automatic calibration, individual RGB gamma adjustment, 3D support, low latency, mapping, and image rotation in 90-degree increments provide additional flexibility for professional LED display applications.

High-density communication connectors help reduce the effects of dust and vibration while providing stable operation in demanding installation environments. The receiving card also supports dual-card backup, firmware program readback, temperature, voltage, and communication status monitoring, along with EMC Class B and RoHS compliance. Its compact design makes it suitable for integrating advanced processing and monitoring capabilities into compatible LED display cabinets.

Product Specifications:

Product Type: LED Display Receiving Card

Application: LED Display Systems

Loading Capacity: 512 x 384 Pixels at 60Hz, 8-Bit Video Sources

Loading Capacity, 10/12-Bit: 256 x 384 Pixels at 60Hz

Maximum Parallel RGB Data Groups: 32

Maximum Serial Data Groups: 64

Transmission Rate: 1G

Image Processing: 18bit+

Pixel-Level Brightness and Chroma Calibration: Yes

Automatic Calibration: Yes

Image Rotation: 90° Increments

Dual-Card Backup: Yes

Firmware Program Readback: Yes

Temperature Monitoring: Yes

Voltage Monitoring: Yes

Communication Status Monitoring: Yes

Input Connector: RJ45

Communication Connectors: High-Density Connectors

Power Supply: 3.3 to 5.5 VDC

Power Consumption: 3W

Certifications: RoHS, EMC Class B

Product Weight: 0.04 lbs.

Product Dimensions (L x W x D): 2.76" x 1.8" x 0.3"
