Descripción
The Blizzard Lighting Verismo Fresnel WW is a professional warm white LED Fresnel fixture featuring a powerful 300W 3200K warm white LED module. Its high-output design makes it ideal for long-distance throws and professional applications including theater, video, production studios, and stage lighting.
The 200mm (8-inch) Fresnel lens produces a bright circular beam with a soft edge, while its DMX-controllable motorized zoom provides adjustable beam angles from 18° to 65°. The fixture also provides 16-bit dimming, four selectable dimming curves, adjustable dimming speeds, and refresh rates from 1,000–8,000Hz.
Designed for professional production environments, the Verismo Fresnel WW combines a high CRI of 97 with flicker-free operation, 1–25Hz strobe effects, and flexible DMX/RDM control. Its standard 10-inch single-slot frame/barndoor holder, black aluminum housing, PowerCON TRUE1-compatible connections, and 3/5-pin DMX connectivity make it a versatile solution for demanding lighting applications.
Key Features
- 300W 3200K warm white LED source.
- High CRI of 97.
- 200mm (8-inch) Fresnel lens.
- 18°–65° motorized zoom.
- 16-bit dimming.
- 1–25Hz strobe effects.
- 1,000–8,000Hz refresh rates.
- Flicker-free operation.
- 10-inch single-slot frame/barndoor holder.
- DMX and RDM control.
Ideal For
- Theater and stage lighting.
- Video and production studios.
- Long-distance lighting.
- Professional Fresnel applications.
- Broadcast and camera environments.
- Concert and event production.
- Architectural lighting.
- Applications requiring high color accuracy.
What’s in the Box
- Blizzard Lighting Verismo Fresnel WW fixture.
Inputs & Outputs
- DMX Input 3-pin and 5-pin male XLR for DMX/RDM control.
- DMX Output 3-pin and 5-pin female XLR for DMX signal pass-through.
- Power Input PowerCON TRUE1-compatible input.
- Power Output PowerCON TRUE1-compatible output for power linking.
- Control Menu Four-button OLED display for fixture settings.
Frequently Asked Questions
What is the Blizzard Lighting Verismo Fresnel WW?
The Verismo Fresnel WW is a warm-white LED Fresnel fixture featuring a 300W, 3200K LED module for theater, video, production studios, and long-distance lighting applications.
What color temperature and CRI does it provide?
It produces a 3200K warm-white output with a high CRI of 97 for accurate and natural-looking color reproduction.
What dimming features are available?
The fixture provides 16-bit dimming, four selectable dimming curves, and user-selectable dimming speeds for smooth and precise output control.
What control protocols does the Verismo Fresnel WW support?
It supports DMX and RDM through 3-pin and 5-pin DMX input and output connections, along with DMX512, master/slave, and standalone operation.
What refresh rates and strobe effects are available?
The fixture offers adjustable refresh rates from 1,000Hz to 8,000Hz and strobe effects from 1–25Hz. Flicker-free resolution also makes it suitable for video applications.
What are DMX channel options?
The Verismo Fresnel WW offers 2-, 3-, 4-, or 6-channel DMX control for flexible fixture operation.
What are power requirements?
It operates from 100–240VAC at 50–60Hz and consumes 283W, with a power factor of 0.99. PowerCON TRUE1-compatible input and output connections are provided.
What are the dimensions and weight of the Verismo Fresnel WW?
The fixture measures approximately 17 × 12 × 18 inches and weighs 21 lbs.
Full Technical Specifications
Light Source & Color Performance
|
LED Engine |
300W Warm White LED |
|
Color Temperature |
3200K |
|
Color Rendering Index |
CRI 97 |
|
Flicker-Free Operation |
Yes |
|
Dimming Resolution |
16-bit |
|
Dimming Curves |
4 selectable |
|
Dimming Speed |
User selectable |
|
LED Refresh Rate |
1,000–8,000 Hz |
|
Strobe Range |
1–25 Hz |
Fresnel Optics & Zoom
|
Fresnel Lens |
200 mm (8-inch) |
|
Zoom Range |
18°–65° |
|
Zoom Type |
DMX-controllable motorized zoom |
|
Frame/Barndoor Holder |
10-inch single-slot |
|
18° Beam Output |
22,034 Lux @ 2.5 m / 5,540 Lux @ 5 m |
|
65° Beam Output |
9,886 Lux @ 2.5 m / 2,768 Lux @ 5 m |
|
Housing |
Black aluminum |
DMX & Electrical
|
Control Protocol |
DMX, RDM |
|
DMX Modes |
2 / 3 / 4 / 6 channels |
|
DMX Connections |
3-pin / 5-pin XLR male & female |
|
Control Modes |
DMX512, Master/Slave, Standalone |
|
User Interface |
4-button OLED display |
|
Power Input |
100–240 VAC, 50–60 Hz |
|
Power Consumption |
283W |
|
Current Draw |
2.33A |
|
Power Factor |
0.99 |
|
Power Connection |
PowerCON TRUE1 compatible in/out |
Physical Specifications
|
Product Weight |
21 lbs. |
|
Product Dimensions (L x W x H) |
18" x 17" x 12" |
