Descripción
The Blizzard Lighting VX600 is a professional all-in-one LED video controller that combines video processing and video control functions in a single compact unit. With six Gigabit Ethernet outputs and support for video controller, fiber converter, and Bypass working modes, the VX600 provides flexible signal management for medium- to high-end LED display applications. It can drive up to 3.9 million pixels, with maximum output dimensions of 10,240 pixels wide by 8,192 pixels high.
Designed for demanding visual applications, the VX600 accepts a variety of video signal formats and supports high-resolution image processing. Stepless output scaling, low latency, pixel-level brightness and chroma calibration, output synchronization, 3D functions, and mosaic input source support provide advanced control for professional LED displays. An intuitive LCD menu interface simplifies setup and operation.
The VX600 is well suited for rental productions, stage control systems, fine-pitch LED screens, and ultra-wide or ultra-high LED displays. Its integrated processing and output architecture provides a streamlined solution for applications requiring high pixel capacity, multiple input formats, and flexible LED display control.
Key Features
- 2-in-1 video processing and control.
- Six Gigabit Ethernet outputs.
- Supports up to 3.9 million pixels.
- Maximum output up to 10,240 × 8,192 pixels.
- Multiple video input formats.
- Stepless output scaling.
- Low-latency video processing.
- Pixel-level brightness and chroma calibration.
- 3D and output synchronization functions.
- Video controller, fiber converter, and Bypass modes.
Ideal For
- Medium- and high-end rental production.
- Stage control systems.
- Fine-pitch LED screens.
- Ultra-wide LED displays.
- Ultra-high LED displays.
- Professional event production.
- Large-format video installations.
What’s in the Box
- NovaStar VX600 All-in-One LED Video Controller.
Inputs & Outputs
- HDMI Inputs 2 × HDMI 1.3 inputs with loop-through
- DVI Inputs 2 × DVI inputs with HDMI 1.3 support and loop-through
- 3G-SDI Input 1 × 3G-SDI input with loop-through
- Ethernet Outputs 6 × Gigabit Ethernet outputs
- Optical Output 1 × 10G optical port
- Monitor Output 1 × HDMI 1.3 monitor output
- PC Ethernet 1 × RJ45 Ethernet port
- USB Type A 1 × USB Type A port for cascading
- USB Type B 1 × USB Type B port for PC connection
- Genlock 1 × Genlock input with loop-through
Frequently Asked Questions
What is the NovaStar VX600?
The VX600 is a 6-port all-in-one video controller that combines video processing and video control in one unit.
How many pixels can the VX600 handle?
It supports up to 3.9 million pixels, with maximum output dimensions of 10,240 pixels wide and 8,192 pixels high.
What video inputs does the VX600 support?
It includes HDMI, DVI, and 3G-SDI inputs, along with loop outputs for flexible signal routing.
How many Ethernet outputs does it have?
The VX600 provides six Gigabit Ethernet outputs for sending processed video to LED displays.
Does the VX600 support fiber output?
Yes. It includes a 10G optical port and supports fiber converter operation.
What are the dimensions and weight?
The VX600 measures 19 × 13.9 × 2 inches and weighs 8.9 lbs.
Full Technical Specifications
General & Key Specifications
|
Product Type |
Lighting Fixture Road Case |
|
Color |
Black |
|
Carry/Transport Options |
Handle, Built-In Wheels |
|
Number of Wheels |
4 |
|
Closure Type |
Latch |
|
Interior Type |
Fixed Dividers |
|
Construction Material |
3/8"" Heavy-Duty Plywood |
|
Exterior Laminate |
Strong ABS Plastic |
|
Aluminum Extrusions |
Machine-Riveted, Tongue & Groove |
|
Corner Protection |
Steel Ball Corners |
|
Interior Protection |
Foam-Lined Protective Interior |
|
Hardware |
Recessed Hardware |
Input & Output Connectors
|
HDMI 1.3 |
2 inputs |
|
HDMI Maximum Resolution |
1920 × 1200 @ 60Hz |
|
DVI |
1 input |
|
DVI Maximum Resolution |
1920 × 1200 @ 60Hz |
|
3G-SDI |
1 input |
|
3G-SDI Maximum Resolution |
1920 × 1080 @ 60Hz |
|
OPT 1 |
Self-adaptive video input/output |
|
OPT 1 Maximum Input |
1x 4K × 1K @ 60Hz or 2x 2K × 1K @ 60Hz |
|
Gigabit Ethernet |
6 ports |
|
Optical Fiber Outputs |
2 |
|
OPT 2 |
Copy or backup output |
|
HDMI 1.3 Output |
1 |
|
HDMI Output Function |
Monitoring or video output |
Video Processing
|
Image Processing |
SuperView III |
|
Output Scaling |
Stepless |
|
Input Cropping |
Free cropping |
|
Layer Adjustment |
Size, position and priority |
|
Mosaic Input |
Supported |
|
Mosaic Sources |
2x 2K × 1K @ 60Hz |
|
Mosaic Cascade |
Up to 4 units |
|
Color Adjustment |
Brightness, contrast, saturation, hue and Gamma |
|
Pixel-Level Calibration |
Brightness and chroma |
Control & Connectivity
|
Control Ethernet |
1 port |
|
USB |
2x USB 2.0 |
|
Genlock |
IN/LOOP |
|
Control Software |
NovaLCT and V-Can |
|
Front Panel Control |
LCD, knob and buttons |
|
Device Cascading |
Supported |
|
Output Synchronization |
Internal source or external Genlock |
Power & Environment
|
Power Input |
100–240V AC, 1.5A |
|
Frequency |
50/60Hz |
|
Rated Power Consumption |
28W |
|
Operating Temperature |
–10°C to +60°C |
|
Operating Humidity |
20%–90% RH, non-condensing |
|
Storage Temperature |
–20°C to +70°C |
|
Storage Humidity |
10%–95% RH, non-condensing |
|
Noise Level |
45 dB(A) at 25°C |
Physical Specifications
|
Product Dimensions (W x D x H) |
19.04"" x 13.83"" x 1.97"" |
|
Product Weight |
8.82 lbs |
|
Shipping Dimensions (W x D x H) |
22.24"" x 6.89"" x 17.72"" |
|
Shipping Weight |
13.89 lbs |
