Descripción
The JBL 305P MkIII is a powered 5-inch professional studio monitor designed for music creators, engineers, content producers, and modern production environments. Its redesigned acoustic platform combines a high-performance silk dome tweeter, advanced low-frequency driver, patented Image Control Waveguide, and Slipstream port to deliver detailed imaging, controlled bass, and consistent off-axis response. With a frequency range extending from 45 Hz to 38 kHz and 120° x 90° coverage, the 305P MkIII provides accurate monitoring across a wide listening area.
The monitor features 43W Class-D amplification for both the low-frequency and high-frequency drivers, providing a total bi-amplified power configuration of 86W. Its maximum RMS SPL reaches 97 dB, while maximum peak SPL reaches 109 dB for demanding monitoring sessions. Four onboard DSP controls provide 81 configurable room-tuning combinations, allowing users to optimize performance for desktop, stand, or wall placement while adjusting boundary compensation and high- and low-frequency response. HF adjustment at 3 kHz and LF adjustment at 300 Hz each offer -2 dB, 0 dB, or +2 dB settings.
The 305P MkIII features a ported 15 mm MDF enclosure with a matte black PVC finish, injection-molded structural ABS baffle, and 2 mm SPCC rear panel. A balanced Neutrik Combo input accepts professional analog connections, while M4 x 8 mounting points and a 75 x 75 mm VESA pattern support flexible installation. The monitor operates from 100–240 VAC and includes a 5.3 kg chassis with compact dimensions of 12.6" x 6.9" x 9.8". Its combination of JBL acoustic technologies, DSP optimization, low-noise amplification, and mounting flexibility makes the 305P MkIII suitable for home studios, professional control rooms, edit suites, and immersive production environments.
Product Specifications:
Product Type: Powered 5-Inch Studio Monitor
Application: Studio Monitoring, Music Production, Mixing, Content Creation, and Post Production
LF Driver Size: 5" / 127 mm
HF Driver Size: 1" / 25 mm
HF Driver Type: Soft Dome
Crossover: 2160 Hz
Power Configuration: Bi-Amplified
HF Driver Power Amp: 43W Class-D
LF Driver Power Amp: 43W Class-D
Total Amplification: 86W Class-D
Frequency Response (±3 dB): 55 Hz to 27 kHz
Frequency Range (-10 dB): 45 Hz to 38 kHz
Low Frequency Extension (-10 dB): 45 Hz
Maximum RMS SPL: 97 dB
Maximum Peak SPL: 109 dB
Coverage (Horizontal x Vertical): 120° x 90°
Input Type: 1 x Neutrik Combo, Balanced
Input Sensitivity (-10 dBV Input): 92 dB / 1 m
Maximum Peak Input Level (-10 dBV / +4 dBu): +7 dBV / +21 dBu
Input Impedance: 20 kΩ
Signal-to-Noise Ratio: 83 dB, A-Weighted, Relative to 1W Output
Sample Rate: 192 kHz
HF Adjustment: -2 dB, 0 dB, +2 dB at 3 kHz
LF Adjustment: -2 dB, 0 dB, +2 dB at 300 Hz
DSP Room Optimization: 81 Configurable Room-Tuning Combinations
Acoustic Technology: Image Control Waveguide and Slipstream Port
Enclosure Type: Ported
Enclosure Construction: 15 mm MDF
Enclosure Finish: Matte Black PVC
Baffle Construction: Injection-Molded Structural ABS, UL 94 V-0
Rear Panel Construction: 2 mm SPCC
Mounting Points: M4 x 8, 4 Top and 4 Bottom
VESA Mounting Pattern: 75 x 75 mm
Magnetically Sensitive Equipment: Suitable
AC Input Voltage: 100–240 VAC ±10%, 50/60 Hz
System Distortion Criteria: <10% THD at Maximum Output with Full Compressor/Limiter Engagement
Electrical Distortion Criteria: <0.1% THD at 1W Output, <1% THD at Full Rated Output
Product Weight: 11.7 lbs.
Product Dimensions (H x W x D): 12.6" x 6.9" x 9.8"
