Descripción
The JBL Control 424C/T 2-Pack delivers smooth, full-range ceiling audio through two professional two-way coaxial loudspeakers, each featuring a 100 mm (4-inch) woofer and 19 mm (0.75-inch) soft-dome tweeter. Integrated CRBI technology provides a consistent 130° conical coverage pattern that helps minimize on-axis hot spots and off-axis cold spots, creating a more uniform listening experience throughout commercial spaces. With a frequency range of 75 Hz–18 kHz, the system is designed to provide clear, balanced reproduction for background music, paging, and installed sound applications.
Flexible 70V/100V & 16Ω Installation
Each Control 424C/T supports both distributed 70V/100V systems and direct 16Ω operation, making the pair suitable for a wide range of professional commercial audio installations. The built-in multi-tap transformer provides 70V taps of 30W, 15W, 7.5W, and 3.7W, while 100V operation supports 30W, 15W, and 7.5W. Each speaker delivers 60W continuous pink-noise power for 2 hours with 240W peak capability, while the integrated enclosure and wide-range mounting system simplify installation across different ceiling constructions.
Modern Design & Efficient Installation
The Control 424C/T combines professional acoustic performance with a refined architectural appearance. Full-face magnetic grilles provide a clean, paintable finish and include safety tethers for secure installation, while redesigned terminal covers offer convenient top and side cable entry with captive hand-screws for tool-free access. The robust captive dogear mounting system accommodates a wide range of ceiling thicknesses, and the IP33-rated construction makes the speakers well suited for demanding commercial environments. The 2-pack includes two loudspeakers with their corresponding grilles, C-rings, and tile rails for installation.
Product Specifications:
Package Quantity: 2 Loudspeakers
Product Type: Two-Way Coaxial Ceiling Loudspeaker
Series: Control 400 Enhanced Coverage Series
Woofer Size: 100 mm (4")
Tweeter Size: 19 mm (0.75") Soft-Dome
Driver Configuration: Two-Way Coaxial
Enclosure Type: Integrated Ceiling Enclosure
Technology: CRBI Coplanar RBI
Nominal Coverage Angle: 130° Conical
Frequency Range (-10 dB): 75 Hz–18 kHz
Frequency Response (±3 dB): 88 Hz–17 kHz
Power Capacity: 120W Continuous Program (2 hrs) per Speaker
Continuous Pink Noise Power: 60W (2 hrs), 40W (100 hrs) per Speaker
Peak Power Handling: 240W (2 hrs), 160W (100 hrs) per Speaker
Sensitivity: 85 dB Average, 100 Hz–10 kHz
Directivity (Q): 3.3
Directivity Index (DI): 5.2 dB
Rated Maximum SPL @ 1 m: 103 dB Continuous Pink Noise, 109 dB Peak
Nominal Impedance: 16Ω
Minimum Impedance: 17.2Ω at 283 Hz LF Range, 16.8Ω at 13 kHz System
Transformer Type: 70V/100V Multi-Tap
70V Transformer Taps: 30W, 15W, 7.5W, 3.7W
100V Transformer Taps: 30W, 15W, 7.5W
Direct Input: 16Ω Low-Impedance Operation
Recommended High-Pass Filter: 70 Hz, 24 dB/oct LR
Transformer Insertion Loss: 0.7 dB @ 3.7W, 0.8 dB @ 7.5W, 0.9 dB @ 15W, 0.9 dB @ 30W
Maximum Input Voltage: 31V RMS (2 hrs), 62V Peak at 16Ω Input
Grille Type: Full-Face Magnetic Grille
Grille Safety: Integrated Safety Tether
Cable Entry: Top and Side
Terminal Covers: Captive Hand-Screw Design
Mounting System: Captive Dogear
Ceiling Cutout Size: 168 mm (6.6")
Ceiling-to-Backcan Height: 173 mm (6.8")
Plenum Installation: Suitable for Most Ceiling Plenum Spaces
Environmental Rating: IP33
Optional Grilles: Black and Square Grille Options Available
Included Accessories: 2 × White Grilles, 2 × C-Rings, 2 × Tile Rails
