Description
The Yorkville 8-Channel Compact Mixer delivers all of the essential features needed in a professional mixer in a convenient, ultra-compact package. High quality 60mm faders throughout, effective fully featured input channel design, 24-bit digital effects, and break switch make the PGM8 the perfect mixer for live music applications and for small installs.
Product Specifications:
Number of Channels: 8
Mono Channel EQ: 3-band
Balance Controls: Yes
Pan Controls: Yes
Channel Overload Protection: Yes
Inputs - XLR (bal): 6
Inputs - 1/4": 6
Inputs - RCA (unbal): 1 stereo pair
Phantom Power: 48 volt + LED indicator
VU Meter: 2 x 10 Segment LEDs
Headphone Monitor Features: yes
Internal Effects: 24 bit stereo 16 effects
Effects Send: 2 (1 internal, 1 external)
Effects Return to Main: Yes
Effects Return to Monitor: Yes
Reverb / Effects Footswitch: Yes
Record Outputs : 1 stereo pair
Mixer - Signal to Noise Ratio (dB): Greater Than -100dB
Mixer - Freq Resp (Tone and EQ Flat,±2dB): 20Hz - 20KHz
Mixer THD (Main out w/ -10dB input): Less Than 0.05%
Typical crosstalk -1 kHz : Greater Than -60dB
CMRR @ 60Hz (min/typ): 55dB/65dB
Power Consumption (typ/max): 26VA (typical)
Chassis Construction: Steel
Dimensions (DWH, inches): 14.2 x 12.8 x 2.8
Dimensions (DWH, cm): 36 x 32.5 x 7
Weight (lbs/kg): 8.5/3.8
