Pioneer Dj XPRS82, XPRS Series 8" Two-Way Full-Range Speaker with DSP

The Pioneer DJ XPRS82, a 8" 2-way full-range, bass reflex, bi-amped active speaker well-suited for mobile DJs, clubs, bands, houses of worship, touring, speaking engagements, or anywhere portable, high-quality audio is required. The Pioneer XPRS82 features a 2000W Class-D amplifier that drives the 8" woofer and a 1" compression driver, which combine for a frequency response of 60 Hz to 20 kHz with a max SPL of 127 dB. The rear panel features a 3-input mixer with channel 1 offering a combo XLR-1/4" connector and gain control for microphone and line levels, while channel two offers a combo XLR-1/4" Hi-Z and line inputs with level gain control. Channel 3 boasts a 3.5mm line input. An XLR line output sums all channels together for adding additional speakers for better coverage. Other features include four EQ DSP modes including Live, Music, Speech, and Monitor as well as 16 User DSP settings for your best sound. The XPRS82 includes a power cord.

Powerful Class-D Amplification

The XPRS2 Series employs Class-D amplification with high output wattage for a powerful and premiere audio experience for performers and listeners alike. The XPRS82 full-range speaker features Class-D 2000W amplification.

High-Quality and Robust Build

Pioneer DJ's all-new XPRS2 Series features a sleek all-black, protective plywood cabinet for performance in harsh indoor and outdoor environments. The series models all come with a durable handle to support system portability and handling during setup and take down. The XPRS2 Series also features rubber feet to create separation and shock absorption between surfaces.

Advanced DSP

DSP Modes: The XPRS2 full-range speakers contain four different DSP preset modes: Live, Music, Speech, and Floor Monitor to address the needs of different listening environments.

DSP User Presets: In addition to the four presets, each XPRS2 full-range speaker includes 16 custom user DSP modes, which can be saved with custom names to ensure the EQ settings are maximized for every scenario.

XPRS152 Full-Range Speaker Design

The XPRS82 is the largest of the full-range speakers in Pioneer DJ's XPRS2 Series. Featuring a 8" woofer and 2" voice coil with a 1" exit compression driver and 1.75" voice coil, the speakers deliver comprehensive sound coverage across mid to large audiences and venues. Boasting a frequency response of 60 Hz to 20 kHz and a maximum SPL of 127 dB, the versatile full-range speaker delivers powerful sound built to thrive in even the harshest of sound environments such as a live DJ set.

Product Specifications

Enclosure Type: Bass-Reflex Loudspeaker

Total Power Capacity:

2000 W Peak

1000 W Program

500 W RMS

Amplifier Class: Class-D

HF Driver: 1 x 1" / 25.4 mm Titanium Compression Driver

HF Voice Coil: 1.75" / 4.45 cm

MF Driver: No

LF Driver: 1x 8" / 20.3 cm Woofer

LF Voice Coil: 2" / 5.1 cm

Frequency Response: 60 Hz to 20 kHz -6 dB

Maximum SPL: 127 dB (Peak)

Protections: Overload, Signal Limiter, Thermal

Audio I/O:

1x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Mic/Line Input

1x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Line/Hi-Z Input

1x 1/8" / 3.5 mm TRS Female Unbalanced Line Input

1x XLR 3-Pin Balanced Mix Output

Network I/O: No

USB I/O: No

Wireless Connectivity: No

Bluetooth: No

Mobile App Compatible: No

EQ: No

Parametric EQ: No

Semi-Parametric EQ: No

Filters: No

Dynamic Processing: Compression, Limiter

Alignment Delay: No

Phase Adjustment: No

Digital Signal Processing: Voicing Modes

AC Input Power: 110 to 240 VAC, 50 / 60 Hz (T 10 A L 250 V)

AC Power I/O: 1x IEC Input

Power Consumption: 800 W

Color: Black

Mounting:

1 x 1.4" / 35 mm Pole Socket (Bottom)

10 x M10 Fly Point

Handles: 1x Each Side

Construction Material: Plywood

Dimensions: 18.1 x 11.9 x 10.7" / 459.7 x 302.3 x 271.8 mm

Weight: 29.1 lb / 13.2 kg
