Description
The ADAM Audio T5V, part of the T-Series of active nearfield monitors, delivers impressive bass response down to 45 Hz, making it a powerful and compact solution for smaller studio environments. Its innovative U-ART tweeter a cost-effective option for high-resolution recording and mixing extends up to 25 kHz and is paired with a precision-engineered waveguide.
A beveled cabinet with a rear-firing bass reflex port and a small footprint allows placement anywhere in your room, no matter how small, and contains built-in DSP-controlled driver crossovers and equalization as well as multi-way analog connections. Powered with a 50 W Class D amplifier for the woofer and a 20 W Class D amplifier for the U-ART tweeter, the T5V produces SPLs of up to 106 dB per pair.
Excellent acoustic characteristics, small dimensions and an outstanding cost/performance ratio make this studio monitor perfectly suited for use in small control rooms in music, video and broadcast production.
State of The Art Technology
ADAM Audio monitors have earned a worldwide reputation as the preeminent tool for sound engineers based on technological innovations that we’ve established in the field of loudspeaker technology.
U-ART Tweeter:
The U-ART 1.9” tweeter design is based on that used in the X-ART and S-ART tweeters employed respectively in the AX Series and S Series monitors.
HPS Waveguide:
The S-ART tweeter comprises the latest iteration of ADAM’s respected folded accelerated ribbon design, produced to tighter tolerances than ever before, and…
PW/M:
ADAM units use the new technology for both the amp and the power supply section (i.e., no more transformers) combined with state of the art input and filter s...
Product Specifications:
General data:
Panel:Rear
Max. Power Consumption:132 W
Delivery Contents:Power cord, Quick Start Guide
Audio Input Connectors:
Analog:XLR / RCA
Input Impedance:10 kOhm / 20 kOhm
Amplification:
Woofer:
Amplifier Type:PWM
Amp. Power RMS:50 W
Tweeter:
Amplifier Type:PWM
Amp. Power RMS:20 W
Acoustics:
Frequency Response:45 Hz – 25 kHz (-6 dB)
THD > 80 Hz:0.5 %
Max. SPL per pair at 1 m:≥106 dB
Crossover Frequency:3 kHz
Drivers:
Woofer:
Basket Diameter:5″
Voice Coil Diameter:1″
Cone Material:Polypropylene
Tweeter:
Type:U-ART
Diaphragm Area:4-inch² (2420 mm²)
Equiv. Diaphragm Diameter:1.9″ (48 mm)
Velocity Transform Ratio:4 to 1
Diaphragm Weight:0.17 g
Waveguide:HPS
Control Options:
Input Sensitivity-10 to +4 dB
Gain:Yes
High Shelf EQ > 5 kHz:– 2 dB, 0 dB, +2 dB
Low Shelf EQ < 300 Hz:– 2 dB, 0 dB, +2 dB
Weight:12.6 lbs. (5.7 kg)
Dimensions (H x W x D): 11.7″ x 7″ x 11.7″ (298 mm x 179 mm x 297mm)
Shipping Weight: 15 lbs.
Shipping Dimensions:14 x 8 x 14 Inches
