Description
The ADJ TB60 is a next-generation multimedia player developed by NovaStar for full-color LED display systems, combining playback and sending capabilities in a single compact solution. Designed for smart content delivery, it allows users to publish and control LED screens using a computer, mobile phone, or tablet, offering flexible and efficient display management for modern installations.
Powered by a high-performance quad-core ARM Cortex-A55 processor, the TB60 features 8GB RAM and 64GB eMMC internal storage, running on an Android-based operating system for smooth and stable operation. It supports multiple control methods including LAN, Wi-Fi, and optional 4G/5G connectivity, along with 6 Gigabit Ethernet ports capable of handling up to 2,300,000 pixels for high-resolution LED screen control.
Built for professional applications, the TB60 supports video, images, audio, text, and office document formats, along with frame synchronization across multiple devices for seamless playback. Advanced features include smart brightness control, scheduled content publishing, and real-time device monitoring via NovaStar VMP software or cloud platforms. With HDMI output, USB ports, and audio connectivity, it delivers a complete and intelligent solution for commercial LED displays and smart city environments.
Product Specifications:
Processor: Quad-Core ARM Cortex-A55
Memory: 8GB RAM
Storage: 64GB eMMC
Operating System: Android-Based System
Control Methods: LAN, Wi-Fi, Optional 4G/5G Module
Video Outputs: 6x Gigabit Ethernet Ports
Max Loading Capacity: 2,300,000 Pixels
Max Resolution Support: 7680 x 3840 Pixels
Supported Media: Video, Images, Audio, Text, Office Documents
Synchronization: Multi-Device Frame Sync
Content Management: NovaStar VMP / Cloud Platform
HDMI Output: 1x HDMI (Real-Time Monitoring)
USB Ports: 2x USB 2.0 (Content Upload)
Audio Output: 3.5mm Jack
Brightness Control: Smart Adjustment
Scheduled Publishing: Yes
Device Monitoring: Real-Time Status Tracking
Operating Temperature: -20°C to +60°C
Power Supply: DC 12V
Certifications: CE, FCC, RoHS
Product Weight: 3.74 lbs.
Product Dimensions(L x W x H): 15.75" x 11.5" x 3.75 "
Shipping Weight: 4.74 lbs.
Shipping Dimensions(L x W x H): 16.75" x 12.5" x 4.75 "
