Chauvet DJ Hurricane Bubble Haze Combination Haze and Bubble Machine

The Chauvet DJ Hurricane Bubble Haze (HBUBBLEHAZE) is a combination atmospheric machine that makes bubbles, haze, or haze-filled bubbles for parties, mobile DJ events and stages. It outputs 4,500 cfm, holds 0.21 gal (0.8 L) in each of its haze and bubble tanks, and takes 4-channel DMX over 3-pin and 5-pin XLR.

Always-ready technology lets it run continuously once it has heated up for 3 minutes. A gravity-fed bubble reservoir recirculates unused bubble fluid to reduce consumption, a variable-speed loft fan pushes the bubbles up into the air, and a built-in cleaning function increases machine longevity and reduces clogs.

Hurricane Bubble Haze specifications

Type	Multi-purpose bubble and haze machine
Effects	Bubbles, haze, or haze-filled bubbles
Output	4,500 cfm
Tank capacity	0.21 gal (0.8 L) each, haze and bubble
Fluid consumption	Haze 0.54 fl oz (16 ml) per minute; bubble 0.74 fl oz (22 ml) per minute
Compatible haze fluids	HDF, HFG (HF5 and HFDJ5 in the EU)
Compatible bubble fluids	BJG (BF5 in the EU)
Bubble system	Gravity-fed reservoir with fluid recirculation, variable-speed loft fan
Heat-up time	3 minutes
Operation	Always-ready technology for continuous running, built-in cleaning function
Control	DMX, 4 channels
DMX connectors	3-pin and 5-pin XLR
Power	120 VAC, 60 Hz or 230 VAC, 50 Hz; 558 W, 4.6 A at 120 V, 60 Hz; 558 W, 2.3 A at 230 V, 50 Hz
Bracket mounting hole	M12
Dimensions	12.2 x 12.3 x 15.5 in (310 x 312 x 394 mm)
Weight	20.2 lb (9.2 kg)
Shipping dimensions and weight	17 x 16 x 20 in, 24 lb
Approvals	CE, RoHS
In the box	Hurricane Bubble Haze, power cord, Quick Reference Guide

Can it make bubbles and haze at the same time?

Yes. It runs bubbles only, haze only, or both together to fill the bubbles with haze.

Can it run through a whole event?

Yes. Always-ready technology lets it run continuously after a 3-minute heat-up.

Which fluids does it use?

Chauvet DJ BJG bubble fluid in the bubble tank and HDF or HFG haze fluid in the haze tank. In the EU, BF5 bubble fluid and HF5 or HFDJ5 haze fluid are also listed as compatible.

How fast does it use fluid?

About 0.54 fl oz (16 ml) of haze fluid and 0.74 fl oz (22 ml) of bubble fluid per minute. The bubble reservoir recirculates unused fluid back into the tank, which reduces consumption.

How do I control it?

Over DMX, with 4 channels on 3-pin and 5-pin XLR connectors, so it fits into an existing lighting and effects rig.

Hurricane Bubble Haze or Hurricane Bubble Haze X2 Q6?

The Hurricane Bubble Haze is the compact model: 20.2 lb, 0.21 gal (0.8 L) tanks, 558 W and 4 DMX channels. The Hurricane Bubble Haze X2 Q6 adds 6 RGB+UV LEDs to light the bubbles, bigger tanks of 0.3 gal (1.3 L) for haze and 0.9 gal (3.5 L) for bubbles, 12 DMX channels and an included WRC wireless remote and omega bracket, at 34.6 lb and 650 W. Both output 4,500 cfm. See more in bubble machines.
