Description
The Chauvet Professional Maverick Force X Spot is a compact, high-performance LED moving spot fixture designed for touring, theatre, broadcast, and corporate productions that require powerful output, precision optics, and versatile control. Equipped with a 520W cool white LED engine, it delivers an impressive 17,325 lumens of output while maintaining a clean, flat field of focus across its beam range. Lightweight yet robust, it is built as a true workhorse fixture capable of handling both short-throw and long-throw applications in demanding professional environments.
At its core, the Maverick Force X Spot features an expansive 3.5° to 57.7° zoom range, enabling seamless transitions from tight aerial beams to wide stage coverage. Its variable CMY color mixing system produces a broad, smooth color palette with accurate tonal rendering, supported by a color wheel with CRI and CTB filters for enhanced color temperature control. Dual gobo wheels-one rotating and one static-offer extensive pattern options, while the built-in iris, five-facet prism, and frost filter allow for detailed beam shaping and atmospheric effects.
The fixture also delivers advanced performance features such as smooth 16-bit dimming and high-speed 65,000 Hz PWM for flicker-free operation in broadcast and camera environments. A comprehensive control suite supports DMX, RDM, sACN, Art-Net, and CRMX, ensuring seamless integration into any lighting system. Additional usability features include True1 power input, USB software updates, NFC fixture setup, battery-backed auto-rotating display, easy setup presets, and failsafe Ethernet connectivity. Altogether, the Maverick Force X Spot combines power, precision, and reliability in a compact design built for modern professional lighting workflows.
Product Specifications:
Light Source: 1 × 520W Cool White LED (6462K)
LED Lifespan: 50,000 Hours
Color Temperature (Full): 6462K
CRI: 72.2 (90 with CRI Filter)
CQS: 69.6 (89.8 with CRI Filter)
TLCI: 50 (78 with CRI Filter)
CTB: 7946K
Lumens Output: 17,325 lm
Beam Angle: 3.5° – 51.3°
Field Angle: 3.7° – 56.3°
Cutoff Angle: 3.9° – 57.7°
Zoom Range: 3.5° – 57.7° (Motorized)
Front Lens Diameter: 145 mm
Dimmer: Electronic (5 Curves)
Strobe Rate: 0 – 25 Hz
Pan: 540° / 360° / 180° selectable
Tilt: 270° / 180° / 90° selectable
Color System: 7 Colors + White + CMY Wheels + CMY Macros
Gobos (Wheel 1): 7 + Open (Rotating, Interchangeable, Indexing)
Gobos (Wheel 2): 9 + Open (Continuous Scroll)
Gobo Size: 24 mm outer / 14 mm image / 1.1 mm max thickness
Focus: Motorised
Zoom: Motorised
Iris: Motorised
Frost: Motorised
Prism: 5-Facet Motorised Rotating
Strobe Rate: 0 – 25 Hz
Control Protocols: DMX, Art-Net
DMX Channels: 22 / 29
Power Consumption: 541–554W (varies by voltage)
Input Voltage: 100–240V AC, 50/60Hz
Power Linking: 2 units @ 120V / 4 units @ 208V / 5 units @ 230V
Power Connector: Seetronic PowerCON IP65
Data Connectors: 3-pin & 5-pin XLR, etherCON IP65
Battery Type: Lithium-Ion (Display Backup)
Battery Life: 1 Hour
Battery Charge Time: 5 Hours
IP Rating: IP20 (Dry Location)
Housing Material: Aluminum Die-cast, Steel, Flame-Retardant Polymer
Noise Level (Max): 42.4 dB(A) @ 1m
Certifications: CE, MET, FCC, UKCA
Weight: 20 kg (44.2 lbs)
Dimensions: 361 × 239 × 646 mm (14.21 × 9.40 × 25.43 in)
Shipping Weight: 54.01 lbs.
Shipping Dimensions (L x W x H): 28.54 x 13.19 x 16.93 in
