Description
The Chauvet Pro Maverick Storm 4 Profile Lightweight 1,250 W LED Yoke Profile Fixture brings indomitable long throw performance to even the largest venues. Its ambitious design launches over 60,000 lumens across incredible distances with commanding brightness. Built to outshine, this Maverick brings more to your show than its long throw. Master the art of domination with a sophisticated variable CMY+CTO system that delivers fantastic color rendering. Double down on crisp gobos to create complex looks with two rotating gobo wheels, two prisms, two frost filters, and an animation wheel to add even more texture. Sharp shutter framing, smooth iris and 8.5:1 zoom complete a Maverick that delivers key light and high energy kinetic effects, in an advanced IP65 alloy body that carries Sunshield tech inside to protect optical components from any solar ingress through its audacious 188mm front lens.
Product Specifications:
Optical
Light Source: 1 LEDs (CW) 1250 W, (4 A), 7500 K, 50,000 hours life expectancy
Color Temperature (at full): 6895 K
CRI: 71.5
CRI with CRI Filter: 91
Front Lens Diameter: 188 mm
Beam Angle: 6.2° to 48.7°
Field Angle: 8.4° to 54.1°
Cutoff Angle: 8.8° to 58.3°
Zoom Range: 6.4° to 58.3°
Lumens – Source: 94,000
Lumens – Output: 60,756
Illuminance: (6.2°) 127,159lux @ 5 m
Illuminance: (58.3°) 4,019lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Dynamic Effects
Pan and Tilt: 540°/270°
Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
Colors: 6 (including CRI and CTB filters) + white, split colors, continuous scroll at variable speeds
Colors: CMY flags, CTO flag
Gobos (1): 6 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Gobos (2): 6 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Gobo Size: Gobo Wheel 1 (rotating): 30 mm (outside), 25 mm (image), 1.1 mm (max. thickness)
Gobo Size: Gobo Wheel 2 (rotating): 30 mm (outside), 25 mm (image), 1.1 mm (max. thickness)
Framing Shutters: 4 Blades, each with dual axis movement, Full blackout.
Framing Shutter rotation: +/- 60° rotation.
Construction / Physical
Dimensions: 18.3 x 11.93 x 32.91 in (465 x 303 x 836 mm)
Weight: 102.5 lb (46.5kg)
Exterior Color: Black
Housing Material: Aluminum diecast, High-impact flame-retardant polymer, Steel
Connections
Power Connection: Seetronic Powerkon IP65
Power Input/Output: Seetronic Powerkon IP65
Data Connectors: 5-pin IP rated XLR, Neutrik IP rated RJ45 Connectors in/out
Cable Length (power): 5 ft (1.5 m)
Control
Control Protocol: Art-Net, DMX, RDM, W-DMX, sACN
DMX Channels: 38 or 55
Art-Net Channels: 38 or 55
Modes/Personalities: 2 personalities (38, 55)
Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 1780 W, 15.07 A @ 120 V, 60 Hz
Power and Current: 1740 W, 8.70 A @ 208 V, 60 Hz
Power and Current: 1760 W, 7.79 A @ 230 V, 50 Hz
Breaker Size: 25 A, 750 V
Certifications / Qualifications
IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
Noise Level (ambient): 36.5 dB level @ 1 m
Noise Level (ECO): 45.8 dB level @ 1 m
Noise Level (auto): 50.1 dB level @ 1 m
Noise Level (FULL): 57.7 dB level @ 1 m
Temperature (Ambient): 4 °F to 113 °F (-20 °C to 45 °C)
What's Included
Maverick Storm 4 Profile
Seetronic Powerkon IP65 power cord to Bare end
140-D Omega bracket with mounting hardware
Optional Accessories
Professional Clamps: CTC-50HC, CTC-50HCN
Safety Cable: SC-07
DMX Cables
IP Rated Seetronic Powerkon Extensions
UPLOAD 08 software uploader
Micro T-1 TRX G65 WDMX Transceiver
FLIGHT CASE TBA
