The Chauvet Pro OVATIONP56WW, Compact Silent WW PAR Light - Warm White is a bright, compact, and virtually silent par with exceptionally high CRI that is ideal for theatrical and studio applications. The sleek, modern-style par produces a homogenized, single-source, flat and even field of light with the same efficient warm white LED system found in the award-winning Ovation E-260WW ellipsoidal. Interchangeable lens plates are included for narrow, medium and wide beam angles. The virtually silent par also features extremely smooth 16-bit dimming, as well as RDM and PWM for set-up ease. The unit accepts standard 7.5” beam shaping accessories.
Product Specifications:
Optical
Light Source: 1 LEDs (WW) 230 W, (3.2 A), 3228 K, 50,000 hours life expectancy
Color Temperature (at full): 3228 K
CRI: 97.9
Beam Angle (Narrow lens): 11.8°
Beam Angle (Medium lens): 23.9°
Beam Angle (Wide lens): 70.9°
Field Angle (Narrow lens): 26.6°
Field Angle (Medium lens): 40°
Field Angle (Wide lens): 106°
Field Angle (Wide lens w/egg crate): 68°
Lumens (w/Narrow lens): 10,326
Lumens (w/Medium lens): 10,728
Lumens (w/Wide lens): 10,687
Dynamic Effects
Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 29 Hz
Dim Modes: 4
Built-in Automated Programs: Yes
Construction / Physical
Dimensions: 12.48 x 12.83 x 14 in (317 x 326 x 363 mm)
Weight: 11.6 lb (5.3 kg)
Exterior Color: Black
Accessory Holder/Gel Frame Size: 7.5 in (191 mm)
Connections
Power Connection: Edison (Local) plug to Neutrik powerCON
Data Connectors: 3- and 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
Control
Control Protocol: DMX, RDM
DMX Channels: 1, 2, 3 or 6
Modes/Personalities: 4 personalities (1, 2, 3, 6)
Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 210 W, 2.278 A @ 100 V, 60 Hz
Power and Current: 205 W, 1.806 A @ 120 V, 60 Hz
Power and Current: 197 W, 1.023 A @ 208 V, 60 Hz
Power and Current: 195 W, 0.916 A @ 230 V, 50 Hz
Power and Current: 194 W, 0.886 A @ 240 V, 50 Hz
Certifications / Qualifications
CE, MET, FCC
IP Rating: IP20, dry location
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
What's Included
Ovation P-56WW
Neutrik powerCON power cord
Gel Frame holder (7.5 in/191 mm accessories)
Wide, medium and narrow lenses
Optional Accessories
Professional Clamps: CTC-50HC, CTC-50HCN
Neutrik powerCON cables
3-pin or 5-pin DMX Cables
Color Blending Filters: DF60X1D, DF20D
Ovation F 7.5″ Barndoor
Ovation 60deg, 7.5” Honeycomb
