dB Technologies B-Hype 10, 10" 2-Way Active Speaker - 260W

The dB Technologies B·H series aims to provide a professional yet efficient sonic performance to all kind of users, combining an extremely efficient CLASS D amplifier with aggressive sound pressure levels (up to 126 dB for this 15” cabinet), while delivering the most accurate sound reproduction. The new B-HYPE 10 is a versatile active speaker. It is equipped with one 1” compression driver (1” voice coil), and one 10” woofer (1.5” voice coil). The dispersion pattern is asymmetrical on vertical axis, and it is diversified (top and bottom) on the horizontal one. This allows a narrower and more efficient sound coverage, and a better performance in case of reverberant environments. The combo input (with source type selection) allows an easy and versatile use, suitable for a dynamic microphone and standard line input. The user can enhance lower and upper frequencies with the convenient DSP preset function. A balanced link output allows the audio connection to a second loudspeaker. This featherweight cabinet (14 lbs/38 lbs) come with a clean and contemporary full grille design, enhancing both portability (3 handles -1xside and 1 on top-) and multifuncionality: each cabinet can be used horizontally as a stage monitor (on both sides) and features a pole mount cup in order to be used on tripods or stacked on dBTechnologies Subs.

Product Specification:

Technical Data

Speaker Type 2-Way Active Speaker

Acoustical data

Usable Bandwidth [-10dB] 55 - 20.000 Hz

Frequency Response [-6 dB] 62 - 19.600 Hz

Max SPL 121 dB

Type HF Compression Driver

HF voice coil 1 "

LF 10 "

LF voice coil 1.5 "

Crossover Frequency 2300 Hz (24 dB/oct.)

Horizontal Dispersionasym metrical 85° up / 120°down

Vertical Dispersion 85° (+25/ -60°)

Amplifier

Amp Technology Custom Made

Amp Class Class D - Passice cooling (convection)

Power Peak 260 W

Processor

Controller DSP 28/56 bit- 48 kHz

Limiter Peak, RMS, Thermal

Controls Volume, Audio Input Sensitivity, DSP Preset

Input

Main Connection VDE

Signal Input Balanced 1xCombo IN (MIC/LINE)

SIGNAL Out (Balanced) 1xXLR OUT (LINK)

Mechanics

Housing Polypropylene

Grille Full Metal Grille

Handles 3 (2 on side 1 on top)

Pole Mount 36 mm
