Description
The DiGiCo DQ-Rack is a compact 6U stage rack that combines professional audio performance with the flexibility of Audinate Dante networking. Designed to deliver the same exceptional quality as DiGiCo's larger rack systems, it provides a space-saving solution without compromising capability. Its rugged construction makes it suitable for touring, broadcast, theaters, corporate venues, and permanent installations. Engineers benefit from powerful remote I/O in a compact form factor.
Flexible Input and Output Configuration
The DQ-Rack features 48 premium microphone inputs and up to 24 line outputs for versatile audio distribution. The final four outputs can be switched between analog line outputs and stereo AES/EBU digital outputs, providing up to eight AES/EBU output channels. This flexible configuration allows engineers to adapt the rack to a wide variety of production requirements. The intelligent I/O architecture supports both live sound and broadcast workflows with ease.
Native Dante Networking
Built around Audinate's Dante protocol, the DQ-Rack enables high-performance audio-over-IP networking using standard Ethernet infrastructure. Existing network installations can be utilized for simple deployment, efficient routing, and flexible system expansion. Dante connectivity allows low-latency transmission of high-channel-count audio across modern production environments. When connected to a DiGiCo console through the DMI-DANTE64@96 interface, all rack inputs and outputs remain fully accessible at both 48kHz and 96kHz.
Seamless DiGiCo Integration
The DQ-Rack is designed to integrate perfectly with DiGiCo digital mixing consoles, providing a seamless extension of the console's I/O capabilities. Communication through the DMI-DANTE64@96 interface ensures reliable audio transport while maintaining exceptional sound quality. Engineers can easily expand system capacity without changing familiar workflows. The rack becomes a natural part of larger DiGiCo production systems for touring, broadcast, and installed applications.
Reliable Redundant Power
For maximum reliability, the DQ-Rack includes dual redundant power supplies as standard. If one power source becomes unavailable, the secondary supply automatically maintains uninterrupted operation to protect critical audio signals. This redundancy is essential for live productions, broadcast facilities, and mission-critical installations where downtime is unacceptable. Engineers gain added confidence through continuous system operation.
Built for Professional Productions
The DQ-Rack is engineered for touring companies, broadcast facilities, theaters, houses of worship, corporate venues, and large-scale installed audio systems. Its combination of Dante networking, flexible I/O, compact 6U design, and redundant power makes it an ideal remote stage rack for modern digital productions. The rugged construction ensures reliable operation throughout continuous professional use. Scalable networking capabilities allow the system to grow alongside production requirements.
What’s in the Box:
- Connections: DANTE (Primary & Secondary) *Requires MOD-DMI-DANTE2 Card for control
- Connectors: EtherCON x 2 for 96kHZ (splitter @ 48kHz)
Product Specifications:
Product Type: 6U Dante-connected digital stage rack.
Rack Size: 6U.
Microphone Inputs: 48 remote-controlled mic inputs.
Line Outputs: Up to 24 analog line outputs.
AES/EBU Outputs: Last 4 outputs switchable to 4 stereo AES/EBU outputs (8 digital channels).
Network Protocol: Audinate Dante.
Console Connectivity: DiGiCo DMI-DANTE64@96 interface.
Sample Rates: 48kHz and 96kHz.
Input/Output Access: Full I/O availability at both supported sample rates.
Power Supply: Dual redundant internal power supplies.
Redundancy: Standard dual PSU operation for uninterrupted performance.
Compatibility: Compatible with DiGiCo SD Series and Quantum Series consoles using DMI-DANTE64@96.
Application: Live sound, broadcast, recording, touring, and fixed installations.
Construction: Compact professional rack-mount chassis.
Cooling: Internal active cooling system.
Product Weight: 37.5 lbs.
Product Dimensions (L × W × H): 19.0" × 17.5" × 10.5"
