Description
The DiGiCo X-Q112-WS-ST combines the power of Quantum processing with an efficient and compact control platform designed for modern live productions. Built to deliver exceptional sonic accuracy, the console provides engineers with the speed and reliability required for demanding shows. Its powerful processing architecture handles complex channel counts and signal routing without compromising performance. Fast response times and intuitive operation help engineers stay focused throughout every production. Whether mixing concerts or broadcasts, the console delivers consistent professional results.
Waves SoundGrid Integration
Native Waves SoundGrid support transforms the console into a complete live processing platform. Engineers can access industry-standard Waves plugins in real time, adding premium EQ, dynamics, reverbs, and creative effects with virtually no latency. The system integrates effortlessly with compatible SoundGrid servers, allowing large plugin counts without overloading console resources. This seamless workflow provides studio-quality processing directly within live productions. Creative flexibility is greatly expanded while maintaining reliable system performance. It is an ideal solution for engineers seeking advanced live sound processing.
Standard (ST) Connectivity
Equipped with a Standard (ST) fiber connector, the X-Q112-WS-ST provides secure and efficient optical communication for professional audio systems. The ST interface supports stable, high-bandwidth transmission across extended cable distances while maintaining signal integrity. It integrates smoothly with compatible DiGiCo equipment and professional fiber infrastructures used in touring and fixed installations. The robust optical connection minimizes interference and ensures dependable network performance. Engineers benefit from reliable system communication throughout demanding productions. It is a proven networking solution trusted by audio professionals worldwide.
Precision Audio Processing
The Quantum platform delivers extensive processing resources across every stage of the signal path. Every channel benefit from advanced equalization, dynamics, filtering, delay, and flexible routing without sacrificing DSP performance. High-resolution internal processing preserves every detail of the original audio source while maintaining exceptional clarity. Powerful onboard resources eliminate the need for excessive external processing hardware. Engineers gain complete creative control while maintaining an efficient workflow. The result is consistently outstanding audio quality for every production.
Streamlined Control Experience
Designed around speed and simplicity, the console's intuitive interface allows engineers to work confidently in fast-paced production environments. The responsive touchscreen provides immediate access to routing, channel processing, metering, and system management. Intelligent layout organization minimizes navigation while improving operational efficiency. Customizable workflows allow the console to adapt to different engineers and production styles. Every control is positioned for fast and accurate operation during live performances.
Built for Demanding Productions
The X-Q112-WS-ST is designed to excel in touring, broadcast, theater, corporate productions, and houses of worship where reliability is essential. Its advanced Quantum processing, integrated Waves SoundGrid platform, and professional ST fiber connectivity create a highly capable live mixing solution. The rugged design withstands the demands of continuous professional use while maintaining exceptional performance. Flexible expansion options ensure the system can evolve alongside changing production requirements.
What’s in the Box:
- DiGiCo Q112 Control Surface - One Multi-Mode Optics ST
- Connections: MADI x 4, Internal Fourier/Dante2 - Hyperport Card
- UB-MADI, DMI Port x 2
- Connectors: BNC, HMA
Product Specifications:
Integrated Networking: Waves SoundGrid
Connector: Standard (ST) Connector
Faders: 12 x 100 mm touch-sensitive, motorized faders.
Touchscreen: 1 x 17" high-brightness, high-resolution LCD touchscreen.
TFT Displays: 18 x full-color TFT LCD displays.
Power Supply: Dual internal redundant PSUs.
Input Channels: 80 mono input channels.
Solo Busses: 2 dedicated solo busses.
Aux/Sub Groups: 24 fully processed Aux/Sub-Group busses.
Matrix: 12 input x 8 output full-processing matrix.
Control Groups: 12 configurable Control Groups (CGs).
Graphic EQ: 12 x 32-band Graphic EQs.
Internal FX: 6 stereo effects processors.
Spice Rack: 6 internal Spice Rack slots.
Mustard Processing: 20 Mustard processing strips.
Nodal Processing: 24 processors with 4-band Parametric/Dynamic EQ.
Local I/O: Stadius 32-bit local I/O.
MADI Connectivity: Up to 4 MADI interfaces or 2 redundant MADI interfaces at 48 kHz; 2 interfaces at 96 kHz.
Optocore Interface: Optional MultiMode Optocore interface.
Sample Rates: 48 kHz and 96 kHz.
DMI Slots: 2 x DMI expansion slots supporting up to 64 I/O per slot.
GPI: 2 input jack connectors.
GPO: 2 output jack connectors.
Processing Delay: Typical 0.5 ms (Mic In to Line Out without channel processing).
Internal Processing: Up to 40-bit floating-point processing.
Converter Resolution: 32-bit A/D and D/A converters.
Frequency Response: ±0.2 dB (20 Hz–20 kHz).
THD+N (Mic In to AES Out): <0.002% @ 1 kHz.
THD+N (AES In to Line Out): <0.002% @ 1 kHz.
Channel Separation: >100 dB @ 10 kHz.
Equivalent Input Noise (EIN): <-127.5 dBu (A-weighted).
Maximum Input Level: +22 dBu.
Maximum Output Level: +22 dBu.
Channel Processing: Mustard and SD processing available on all input channels.
Input Controls: Analog Gain, Phase Invert, Gain Tracking, Digital Trim, Variable Delay, and DiGiTube.
Filters: HPF/LPF with 24 dB/octave slope.
Equalization: 4-band Parametric/Dynamic EQ on every input channel.
Dynamics: Compressor, Multiband Compressor, De-Esser, Gate, Ducker, and External Input Compressor.
Insert Points: 2 insert points per channel.
Direct Outputs: Available on every input channel.
Bus EQ: 8-band EQ with Parametric and Dynamic EQ options.
FX Library: Delays, Reverbs, Choruses, Pitch Shifters, and Audio Enhancer.
Spice Rack Effects: 6-band Dynamic Multiband Compressor/Expander and 6-band Dynamic EQ.
Mustard EQ: 4-band EQ with All-Pass Filter capability.
Mustard Dynamics: RMS, VCA, Optical, and FET compressor models plus Gate and Ducker.
Multiband Compressors: Available on every channel, buss, and nodal processor.
Dynamic EQ: Available on every channel, buss, and nodal processor.
DiGiTube: Available on every input channel and buss.
Virtual Soundcheck: Fully supported for recording and playback workflows.
Product Weight: 46 lbs.
Product Dimensions (L x W x H): 30.3" x 23.2" x 10.2"
