Description
The DiGiCo X-Q326-W-WS-ST combines Quantum FPGA processing with Ultimate Stadius technology to deliver exceptional sound quality and ultra-low latency. Designed for live touring, broadcast, theater, and corporate productions, it offers outstanding processing power in a compact control surface. Engineers benefit from fast operation, intuitive workflows, and advanced mixing capabilities. The console handles demanding productions with confidence and precision. It is built to meet the expectations of modern professional audio engineers.
Integrated Waves SoundGrid
The factory-installed W Package includes integrated Waves SoundGrid networking for seamless live plugin processing. It supports direct integration with Waves SuperRack SoundGrid, allowing engineers to use premium EQs, compressors, reverbs, and dynamics with extremely low latency. This reduces the need for external processing hardware while delivering studio-quality sound in live environments. The built-in Waves interface simplifies system configuration and workflow. It is ideal for professional touring and broadcast applications.
Standard (ST) Optocore Connectivity
This model features a Standard (ST) fiber connector for Optocore networking, providing secure long-distance digital audio transport between consoles and stage racks. ST fiber connections are widely used in touring systems, theaters, and permanent installations because of their reliability and stable performance. They maintain excellent signal integrity while minimizing interference. The robust fiber connection ensures dependable communication throughout every production. It is trusted in professional live sound environments.
Fast and Efficient Workflow
The Quantum 326 is equipped with 26 touch-sensitive motorized faders, dual 17-inch high-resolution touchscreens, and 51 individual TFT channel displays. Engineers can quickly access routing, snapshots, processing, and monitoring functions with minimal navigation. The ergonomic floating chassis enhances comfort during long mixing sessions. Clear visual feedback improves speed and accuracy in demanding live environments. Every control is designed for maximum operational efficiency.
Powerful Built-In Processing
Supporting up to 128 input channels, 64 fully processed buses, and a 24×24 matrix, the console easily manages complex productions. Built-in Mustard Processing, Spice Rack FPGA plugins, Nodal Processing, True Solo, and premium internal effects provide extensive creative flexibility. The Quantum processing engine maintains smooth performance under heavy workloads. These advanced tools reduce reliance on external hardware while delivering outstanding sonic results. The console is engineered for professional live production.
W Package Advantages
The W Package is designed for engineers who require integrated Waves SoundGrid networking directly from the console. It enables efficient plugin processing with compatible SoundGrid servers while maintaining low latency and dependable performance. Combined with Ultimate Stadius technology and Standard ST Optocore connectivity, it provides a complete solution for demanding live sound applications. This configuration is ideal for touring companies, broadcast facilities, rental providers, and fixed installations.
What’s in the Box:
- MADI x 6, Optics x 1
- Internal Waves Card
- UB-MADI, DMI Port x 2
- Connectors: BNC, ST
Product Specifications:
Connector: Standard (ST) Connector
Integrated Networking: Waves SoundGrid
Package: W Package (Integrated Waves SoundGrid)
Faders: 26 × 100 mm Touch-Sensitive Motorized
Display Screens: Dual 17" High-Brightness LCD Touchscreens
Input Channels: 128
Aux/Group Busses: Up to 64 (Mono, Stereo, LCR, LCRS, 5.1)
Matrix: 24 × 24 with Full Processing
Control Groups: Up to 24
Internal Effects: Up to 24 Stereo FX Engines
Spice Rack: 8 Mono / 4 Stereo Rack Slots
Mustard Processing: 36 Processing Strips
Nodal Processing: 64 Nodal Processors
Mic/Line Converters: 32-bit
MADI Interface: 6 × 48 kHz or 3 × 96 kHz (BNC)
Optocore Interface: Optional Dual Loop
DMI Slots: 2 × DiGiCo Multichannel Interface
Sampling Rates: 48 kHz / 96 kHz
GPI/GPO: 16
Waves Support: Optional
External Sync: Word Clock, AES, MADI, Optocore
Frequency Response: ±0.15 dB (20 Hz–20 kHz)
THD: <0.002% @ Unity Gain
Channel Separation: Better Than 120 dB
Residual Output Noise: <100 dBu
Microphone Input Noise: Better Than -128 dB EIN
Maximum Input Level: +22 dBu
Maximum Output Level: +22 dBu
Processing Delay: 1 ms Typical @ 96 kHz
Internal Processing: Up to 40-bit Floating Point
A/D & D/A Conversion: 32-bit
Input Gain: -20 dB to +60 Db
Digital Trim (Input): -40 dB to +40 dB
Output Trim: -20 dB to +60 dB
Channel Delay: Up to 1.3 Seconds
Output Delay: Up to 1.3 Seconds
HPF/LPF: 20 Hz–20 kHz, 24 dB/Octave
Input EQ: 4-Band Parametric/Dynamic EQ
Output EQ: 8-Band Parametric/Dynamic EQ
EQ Gain: ±18 dB
EQ Frequency Range: 20 Hz–20 kHz
Dynamic EQ: Supported
Compressor Types: Single-Band & 3-Band Multiband
Gate/Ducker: Yes
De-Esser: Yes
DiGiTuBe Processing: Drive & Bias Controls
Insert Points: Dual (Pre & Post EQ/Dynamics)
Fader Level: ∞ to +10 dB
Mustard Processing: Tube & Amp Emulation, Vintage Compressors, Optical Compressor, FET Limiter
Power Requirements: 100–240 VAC, 50/60 Hz, 295 VA
Product Weight: 114.6 lb
Product Weight (With Flight Case): 330.7 lb
Product Dimensions (L × W × H): 44.3" × 31.7" × 19.0"
Flight Case Dimensions (L × W × H): 49.3" × 25.4" × 45.3"
