Description
The DiGiCo X-Q5-W-WS-ST combines the acclaimed Quantum 5 platform with the Ultimate software package, providing exceptional processing power for live sound, broadcast, and theater productions. Its FPGA-based engine delivers ultra-low latency, outstanding audio quality, and remarkable system responsiveness. Advanced Quantum features expand creative mixing possibilities while maintaining a smooth workflow. Every channel benefit from powerful onboard processing. The console is engineered for demanding professional applications.
Integrated Waves SoundGrid
Built-in Waves SoundGrid connectivity enables seamless integration with Waves SuperRack and SoundGrid servers for real-time plugin processing. Engineers can control supported plugins directly from the console while maintaining extremely low latency. The system supports reliable live performance with redundant SoundGrid configurations. This integration expands creative processing without reducing console performance. It is ideal for complex touring and broadcast environments.
Reliable ST Fiber Connectivity
The Standard ST fiber Optocore interface provides high-capacity digital audio transport across long distances. It connects effortlessly with DiGiCo stage racks and Optocore devices while ensuring stable, low-latency communication. The fiber network supports large-scale productions with dependable redundancy. System expansion remains simple as production requirements increase. It delivers consistent performance for touring, festivals, and permanent installations.
Efficient Mixing Workflow
Three high-resolution 15-inch touchscreen displays offer fast access to routing, processing, snapshots, and system control. Thirty-seven motorized touch-sensitive faders provide accurate operation with quick layer changes. Custom macros and flexible user layouts improve workflow efficiency. Engineers can react instantly during live productions. The intuitive interface minimizes setup time while maximizing control. Every function is designed for professional operation.
Extensive Processing and Expansion
The console supports up to 256 processing channels, 128 fully processed buses, and comprehensive routing flexibility for demanding productions. Two dedicated DMI slots allow expansion with Dante, MADI, Waves, KLANG, Hydra2, AVB, and additional networking formats. Advanced processing tools include Dynamic EQ, Mustard Processing, Spice Rack effects, and DiGiTuBes emulation. This flexibility allows the console to adapt to virtually any production requirement. It integrates easily into modern audio infrastructures.
Built for Professional Productions
Designed for continuous operation, the X-Q5-W-WS-ST offers the durability and reliability required by rental companies, touring engineers, broadcast facilities, and fixed installations. Redundant power architecture and premium components ensure dependable performance under demanding conditions. Its ergonomic control surface reduces operator fatigue during long events. Powerful networking and advanced processing deliver consistent results every show. It is a trusted solution for world-class live audio production.
What’s in the Box:
- Q5 & SD5 3 Piece Flight Case with Pullout Keyboard on Casters
- Connection: MADI x 8, Optics x 1
- Internal Waves Card
- UB-MADI, DMI Port x 2
- Connectors: BNC, ST
Product Specifications:
Integrated Networking: Waves SoundGrid
Connector: Standard ST Optocore fiber connectors.
Faders: 37 x 100mm touch-sensitive, motorised
Screens: 3 x 15" LCD high-resolution touch screens
Meterbridge: 2 x Custom Mounted LCD high-resolution TFT-LCD screens
Internal PSU: 2 x Internal Power Supplies
Processing Channels: Up to 330 (combination of Input Channels, Aux, and Solo Group Busses)
Busses: Up to 128 Aux/Group busses with full processing (Mono, Stereo, LCR, 5.1)
Matrix: Up to 36 Inputs / 36 Outputs with full processing
Control Groups: Up to 36, selectable for VCA-style, Moving Fader, or Mute Group
Graphic EQ: 32 x 32-band, Gain ±12dB
Internal FX: Up to 36 stereo effects, including 16 floating-point reverbs
Local I/O: 8 x Mic/Line I/O, 8 x AES I/O
MADI Interfaces: 8 x MADI @ 48kHz, 4 redundant @ 96kHz (BNC connectivity)
Optocore: Standard (Dual Loop – Optional)
Sampling Rates: 48kHz / 96kHz
GPIO: 2 x DSub37
DMI: 2 x DiGiCo Multichannel Interface Slots
Waves: Fitted as Standard
External Sync: Word Clock, AES, Video, MADI, Optocore
Power Requirements: 90V–260V AC, 50–60Hz, 790VA
Sample Rate: 48kHz or 96kHz
Processing Delay: 2ms typical @ 48kHz (253 Channels), 1.1ms @ 96kHz
Internal Processing: Up to 40-bit Floating Point
A/D & D/A Conversion: 24-bit Converter Bit Depth
Frequency Response: ±0.6dB (20Hz–20kHz)
THD: <0.05% @ Unity Gain, +10dB Input @ 1kHz
Channel Separation: Better than 90dB (40Hz–15kHz)
Residual Output Noise: < -90dBu Typical (20Hz–20kHz)
Microphone Input Noise: Better than -126dB Equivalent Input Noise (EIN)
Maximum Output Level: +22dBu
Maximum Input Level: +22dBu
Channel Name: User-defined with Presets
Channel Selection: Mono, Stereo, or Multi
Input Routing: Main and Alternate Input
Analogue Gain: -20dB to +60dB
Phase: Normal / Reverse
Digital Trim: -40dB to +40dB (Input), -20dB to +60dB (Output)
Delay: Greater than 1 second with Coarse and Fine Control
DiGiTuBe: Drive 0.01–50.0, Bias 0–6
Low Pass Filter: 20Hz–20kHz, 24dB/Octave
High Pass Filter: 20Hz–20kHz, 24dB/Octave
Insert A: Pre EQ/Dynamics On/Off
Input EQ: 4-Band Parametric or Dynamic EQ with Shelf Options
Output EQ: 8-Band EQ with Dynamic EQ Support
EQ Gain: ±18dB
EQ Frequency Range: 20Hz–20kHz
EQ Q Range: 0.1–20 (Parametric), 0.10–0.85 (Shelf)
Dynamic EQ: Over/Under Mode with Adjustable Threshold, Attack, Release, and Ratio
Dynamics 1: Single-Band or 3-Band Multiband Compressor with Auto Gain
Dynamics 2: Gate, Ducker, and Compressor with Sidechain Support
De-Esser: Adjustable Threshold, Release, Ratio, and Frequency Width
Insert B: Post EQ/Dynamics On/Off
EQ/Dynamics Order: EQ→Dynamics or Dynamics→EQ
Mute: Channel Mute / Hard Mute
Solo: Solo Bus 1, Solo Bus 2, Both, Auto Solo
Channel Safe: Input, EQ, Dynamics, Aux, Pan, Fader/Mute, Inserts, Busses, Directs, or Full Safe
Output Routing: Busses, Outputs, Inserts, and FX
Direct Output: On/Off, Pre-Mute, Pre-Fade, Post-Fade, Level ±18dB
Fader: 100mm Motorised Fader, ∞ to +10dB
Product Weight: 257 lbs.
Product Dimensions (L x W x H): 57.68" x 32.99" x 18.03"
