Elation NXT100 Professional NX Touch 14 x Fader DMX Control for ONYX

The Elation NXT100 Professional NX Touch 14 x Fader DMX Control for ONYX is a powerful yet simple control surface for the ONYX platform, fully compatible with all ONYX consoles and PC software, NX Touch is a plug-and-play solution with an innovative control surface like no other lighting console.

14 touch faders allow control of playbacks and fixture parameters while 20 velocity-controlled pads allow for new types of effects. Additional programming buttons such as Record, Edit, Update, Load and Clear are accessible directly from the NX Touch control panel. NX Touch includes one DMX port for direct control of any compatible DMX device.

Product Specifications:

Surface

Bank Navigation Up/Down with numerical display
Main Go section: Snap, Release, Pause and Go buttons
Command Buttons: Record, Edit, Update, Load, Clear
Multifunction Mode Select button
Fixture Selection buttons: Last, Next, highlight
4x Parameter Select buttons
4x Parameter Adjust touch faders
10x Function velocity pads
10x Playback touch faders with 3 buttons
(2x touch pad, 1x velocity pad)

Connections

DMX Out: 1x 5pin locking XLR
USB Input: USB B 2.0

Requirements

Windows 10
Intel Core i3 processor 6th Generation+
8 GB RAM
SSD Drive
40 GB available disk space
Widescreen monitor, minimum 1280 wide, 768 high (capacitive multi-touchscreen recommended)
USB 2.0 port
10/100 Ethernet port for Art-Net DMX output
100/1000 Ethernet port for X-Net, Remote operation and sACN

Package Dimensions: 16.03 x 2.03 x 2.11"

Package Weight: 4.80 lb
