Elation PIX685 IP65 Rated 200-Watt Power Amp for Pixel Wash 40IP

The Elation PIX685, IP65 Rated 200-Watt Power Amplifier for Pixel Wash 40IP is designed to work in conjunction with the Elation Pixel Driver 170IP, Pixel Driver 1000IP or the Pixel Driver 4000V2. Each Pixel Amp 200 can power up to 8 Pixel Wash 40IP’s in standard mode or 5 Pixel Wash 40IP’s in HI Power mode. Up to 4 Pixel Amp 200’s can be used in line for each driver output giving you the ability to control a total of 40 Pixel Wash 40IP’s in standard mode or 25 Pixel Wash 40IP’s in HI Power mode for each driver output. The unit comes equipped with Power In, Data In/Out pigtail connections, and is IP65 rated, which protects the unit from the ingress of dust, as well as low pressure water jets sprayed from any direction.

Product Specifications:

Control / Connections:

Art-NET | sACN | Kling-NET Protocol Support

1 4-pin Power Input

1 4-pin Data Input

1 4-pin Data Output

Size / Weight:

Length: 3.1” (78mm)

Width: 9.2” (233mm)

Height: 2.9” (74mm)

Weight: 2.9lbs (1.3kg)

Electrical:

Power Input: 100-240V, 50/60Hz

Power Output: DC24V, 8.3A Max

200W Max Power Consumption

Approvals / Ip Rating:

CE | ETL | IP65 (Temporary Outdoor Use Only)
