Description
The JBL Control 414C/T Micro 2-Pack delivers professional two-way coaxial ceiling audio in a compact, low-profile design. Each speaker features a 100 mm (4-inch) woofer and 12 mm (0.5-inch) PEI dome tweeter, providing clear full-range reproduction while maintaining a shallow 105 mm (4.13-inch) enclosure depth. This makes the speaker particularly suitable for installations where available ceiling plenum space is restricted.
Wide Coverage & Extended Frequency Response
With a 69 Hz–25 kHz frequency range, 86 dB sensitivity, and an extremely wide 160° conical coverage pattern, the Control 414C/T Micro provides consistent sound across broad listening areas. Its 93 Hz–21 kHz ±3 dB frequency response supports clear speech, background music, paging, and commercial audio applications. The speaker can reach up to 98 dB continuous pink-noise SPL and 104 dB peak at 1 meter when operating from the 8Ω tap.
Efficient Installation & Modern Appearance
The Control 414C/T Micro is engineered for efficient and repeatable installation with convenient top and side cable-entry options. Its captive dogear mounting system accommodates a wide range of ceiling thicknesses, while the integrated enclosure provides a clean and secure installation. The full-face bezel-less magnetic grille includes a safety tether and can be painted to coordinate with modern interior décor.
Product Specifications:
Package Quantity: 2 Speakers
Product Type: Two-Way Coaxial Ceiling Loudspeaker
Series: Control 400 Standard Coverage Series
Speaker Configuration: Two-Way Coaxial
Woofer Size: 100 mm (4")
Tweeter Size: 12 mm (0.5")
Driver Mounting: Coaxial
Enclosure Type: Integrated Low-Profile Enclosure
Enclosure Depth: 105 mm (4.13")
Frequency Range (-10 dB): 69 Hz–25 kHz
Frequency Response (±3 dB): 93 Hz–21 kHz
Power Capacity: 45W Continuous Program (2 hrs), 22.5W Continuous Pink Noise (2 hrs), 15W Continuous Pink Noise (100 hrs) per Speaker
Peak Power Handling: 90W Peak (2 hrs), 60W Peak (100 hrs) per Speaker
Sensitivity: 86 dB
Nominal Coverage Angle: 160° Conical
Directivity (Q): 2.9
Directivity Index (DI): 4.6 dB
Rated Maximum SPL @ 1m: 98 dB Continuous Pink Noise, 104 dB Peak at 8Ω Tap; 95 dB Continuous Pink Noise, 101 dB Peak at 10W Tap
Nominal Impedance: 8Ω
Minimum Impedance: 6.5Ω @ 290 Hz
Transformer Type: 70V/100V Multi-Tap
70V Transformer Taps: 10W, 5W, 2.5W, 1.2W, 0.6W
100V Transformer Taps: 10W, 5W, 2.5W, 1.2W
Recommended High-Pass Filter: 70 Hz, 24 dB/oct LR
Transformer Insertion Loss: 0.1 dB @ 0.6W, 0.5 dB @ 1.2W, 0.7 dB @ 2.5W, 1.0 dB @ 5W, 1.1 dB @ 10W
Maximum Input Voltage: 9.9V RMS / 19.8V Peak at 100 hrs; 12.1V RMS / 24.2V Peak at 2 hrs
Overload Protection: PTC Power Limiting
Grille Type: Full-Face Bezel-Less Magnetic Grille
Grille Safety: Safety Tether Included
Cable Entry: Top and Side
Ceiling Mounting: Captive Dogear System
Plenum Installation: Suitable for Air Handling Spaces
Environmental Rating: IP32 per EN/IEC 60529
Operating Temperature: 0°C–45°C
RoHS Compliance: EU RoHS Directive 2011/65/EU, as amended by EU Delegated Directive (EU) 2015/863
Safety Ratings: UL 2043, NFPA 90A, NFPA 70
Commercial Speaker Listing: UL 1480A
CSA Certification: CSA C22.2 No. 205 Signal Equipment
Transformer Certification: UL Registered
Primary Applications: Commercial Spaces, Hotels, Museums, Retail Stores, Cafés, Reception Areas, Educational Facilities, Business Music, Paging Systems
