Description
The JBL CSS8004 Commercial Series Ceiling Speakers provide excellent performance for paging and background music applications. High sensitivity across the product line provides maximum sound level, even at low tap settings.
Product Specifications:
Drivers: 100 mm (4 in)
Sensitivity: 90 dB (2k - 6k Hz)
Frequency Range (-10 dB) Driver/Grille Assembly: 85 Hz – 18 kHz
Installed in CSS-BB backcan: 130 Hz – 18 kHz
Coverage Angle: 175° conical
Driver Continuous Power Handling: 15 Watts
Transformer Taps: 5W, 2.5W, 1.3W
Transformer Taps: 5W, 2.5W, 1.3W, 0.7W
Transformer Taps: 5W, 2.5W, 1.3W, 0.7W
Transformer Insertion Loss: 1.5 dB Maximum
Transformer Connection: Bare wire
Motor Mass: 200 g (7 oz)
Matching CSS Backcan: CSS-BB4
Other Compatible Backcans: N/A
Bolt Mounting Circle to Backcan: 4 points on 165 mm(6.5 in) diameter
Cutout DiameterOpen-back: 125 mm (5.0 in)
In CSS-BB backcan: 170 mm (6.7 in)
Depth (behind grille): 94 mm (3.7 in)
Grille Diameter: 198 mm (7.8 in)
Net Weight (each): 0.90 kg (1.0 lb)
Power Rating: See transformer taps
Maximum SPL (1m): 97 dB (top 25V/70V/100V tap)
Input Connectors: Bare wire
Backcan: formed steel (accessory)
Baffle/Rim: Metal
Ceiling Cutout Size: 125 mm (5.0 in)
Plenum Usage: Yes, with accessory backcan
Color: White
