Lake People DIGI-TOOL-F612 Digital Audio and Wordclock/AES-iD Splitter

The Lake People DIGI-TOOL F612 is a professional-grade, dual-module digital distribution amplifier for AES/EBU, AES-id, and Word Clock signals. Designed for studio, broadcast, and live sound applications, the F612 offers two independent distribution stages - a transformer-balanced AES/EBU splitter with four XLR outputs, and a BNC-based AES-id/WCLK splitter with eight outputs. Both modules feature high-sensitivity inputs for signal regeneration and high output drive for long cable runs. Adjustable output impedance, AES-3id compatibility, and “Superclock 256 Fs” support make the F612 exceptionally versatile. An optional MULTI-SYNC UNIT adds comprehensive sync and clock control features for demanding digital workflows.

Product Specifications:

Type: Dual-module digital distribution amplifier for AES/EBU, AES-id, and WCLK

Module 1: AES/EBU splitter – 1 input, 4 outputs (XLR, 110 Ω, transformer balanced)

Module 2: AES-id/WCLK splitter – 1 input, 8 outputs (BNC, 75 Ω unbalanced; switchable to 50 Ω)

Bit Depth: 24-bit

Sample Rate: Up to 192 kHz

Input Sensitivity: < 200 mV

Input Impedance: 110 Ω (XLR), 75 Ω (BNC)

Output Impedance: 110 Ω (XLR), 75 Ω or 50 Ω (BNC)

Housing: 19" rackmount stainless steel, 1U height

Power Supply: Internal 230 V / 115 V AC (90–260 V AC universal)

Dimensions: 19 x 6.5 x 1.7"

Shipping Weight: 6 lbs.

Shipping Dimensions (LxWxH): 21.7 x 10.7 x 5.1"
