Description
The LEA Professional CS122 is a compact 2-channel smart power amplifier purpose-built for modern AV installations, delivering 120W per channel at 4Ω, 8Ω, 70V, and 100V. Designed to provide powerful and flexible amplification in a space-saving format, the CS122 features advanced 32-bit/96kHz Analog Devices DSP, Class D output technology, and a highly efficient power supply for reliable performance with reduced power consumption.
The CS122 offers comprehensive network control and monitoring through a built-in Wi-Fi access point, existing Wi-Fi networks, or LAN Ethernet connections. Its browser-based user interface enables seamless setup and control on any device, without additional software, while LEA Cloud provides remote access and monitoring from anywhere without a VPN. Advanced DSP capabilities include input routing, sample rate conversion, 48dB/octave crossover filters, 8-band parametric EQ, adjustable speaker limiters, real-time load monitoring, and flexible signal management through Web UI, SharkWare, or cloud platforms.
Built for demanding professional installations, the CS122 supports both low-impedance and high-impedance applications with selectable 70V or 100V operation on each channel. Smart Power Bridge technology allows increased power delivery to a single channel while maintaining independent operation of the second channel. Featuring flexible analog inputs, Amphenol Anytek connectors, remote monitoring I/O, third-party API support, comprehensive protection features, and a slim half-rack chassis, the CS122 provides a powerful and scalable solution for commercial audio, hospitality, education, and advanced AV environments.
Product Specifications:
Input Channels: 2 Balanced Inputs, 2 RCA Inputs
Input Sensitivity: 26dB / 34dB / Mic Level
Input Type: Analog
Input Configuration: User Selectable
THD+N: 0.1% (20Hz–20kHz)
Frequency Response: 20Hz–20kHz ±0.5dB
Frequency Response (2Ω): -2.5dB @ 20kHz
Signal to Noise Ratio: 102dB (20Hz–20kHz @ 8Ω)
Crosstalk: 70dB (20Hz–20kHz)
Amplifier Class: Class D
Output Technology: Smart Power Bridge Technology
Bridged Output: Yes
DSP Processor: Analog Devices Sigma DSP
DSP Sample Rate: 96kHz
DSP Core: 32-Bit
Sample Rate Converter: Yes
Input Matrix: Routable Matrix
Matrix Mixer: Yes
Crossover Filters: IIR Filters
Crossover Slope: Up To 48dB/Octave
Crossover Types: Linkwitz Riley, Butterworth
Parametric EQ: 8-Band Per Channel
Output Delay: 100ms Per Channel
Protection: DC, VHF, AC Mains, Overtemperature, Current Limiter
Fan Protection: Fan Fault Detection
Limiter Control: Peak Voltage, RMS Voltage
Load Monitoring: Real-Time Load Monitoring
Pilot Tone Detection: Internal and External Sources
User Interface: Web Browser
Control Options: API Control, Cloud Control, SharkWare
External I/O Input: Remote On/Off
External I/O Output: Amplifier Health Status
GPIO: 2 General Purpose I/O Pins
AC Input: 100VAC–240VAC ±15%
AC Frequency: 50Hz / 60Hz
Power Supply: Universal Switch Mode
Cooling System: Variable Fan Speed Cooling
Cooling Direction: Front to Rear
Fan Noise (Idle): 50dB @ 1m
Fan Noise (50%): 57dB @ 1m
Fan Noise (Full Speed): 63dB @ 1m
Product Weight: 7 lbs / 4.1 kg
Product Dimensions (L x W x H): 11.82” x 8.58” x 1.71″ (300.11mm x 218mm x 43.5mm)
Shipping Dimensions (L x W x H): 18” x 11” x 2.75” (457.2mm x 300mm x 69.85mm)
