QSC AD-C6T-HC 6.5" 2-Way High Ceiling & Blind Mount 75 Deg 6.5 Inch - Pair

The QSC AD-C6T-HC, 6.5 Inch 2-Way High Ceiling and Blind Mount 75 Deg Ceiling Speakers - 70/100V - White is a pair of high-power, passive, ceiling speakers well suited for ballrooms, airports, atriums, and lobbies. Designed to deliver a remarkable foreground or background music experience, each ceiling-mount loudspeaker offers premium quality, high power handling, and tight coverage to ensure the optimal audio experience in spaces with high ceilings.

The speaker requires up to 120W of power to drive the 6.5" woofer and 1.4" dome compression driver which combine to offer a frequency range of 45 Hz to 20 kHz (-10 dB) and a max SPL of 116 dB. The coaxial design ensures that both drivers are phase accurate for clear and precise sound over the 75° conical coverage pattern. The speakers are also compatible with 70/100V amplifiers for even more flexibility when deploying. The pair of speakers include Euroblock connectors, cutout guides, and mounting hardware.

Product Specifications:

Active/Passive: Passive

Number of Included Speakers: 2

Speaker Configuration: 2-Way

Power Handling: 120 W

Constant Voltage / Transformer Taps:

70 V: 60 / 30 / 15 / 7.5 W or 16 Ohms Bypass

100 V: 60 / 30 / 15 W or 16 Ohms Bypass

Impedance: 14.97 to 16 Ohms

Enclosure Type: Sealed

HF Driver: 1x 1.4" / 35.6 mm Dome Compression Driver

LF Driver: 1x 6.5" / 165.1 mm Paper Woofer

LF Voice Coil: 1.75" / 44.45 mm

Magnet:

LF: Ferrite

Frequency Range: 45 Hz to 20 kHz -10 dB

Maximum SPL:

110 dB (Continuous)

116 dB (Peak)

Sensitivity: 90 dB

Coverage Angle: 75° (Conical)

Directivity:

10 dB (Directivity Index)

10 (Directivity/Q Factor)

Crossover: 2.5 kHz

Inputs/Outputs: 1x Block 4-Pin Speaker Input/Thru

Environmental Resistance: No

Color: White

Mounting: In-Ceiling

Construction Material: ABS, Steel

Dimensions: 13.4 x 13.4 x 12" / 340.4 x 340.4 x 304.8 mm

Weight: 19 lb / 8.6 kg (Each Speaker)
