Description
The RCF DUP 5EN is a highly efficient and versatile 2-way passive loudspeaker designed for wall installations, ideal for environments where clear and intelligible alarm messages are essential. Built with high-quality components, flameproof ceramic terminal blocks, and thermal fuse protection, it offers exceptional safety and reliability even under extreme conditions, such as high temperatures encountered during fires. This makes the DUP 5EN a perfect choice for public address systems, fire alarms, and other safety-critical audio applications.
Equipped with a 5.5-inch full-range transducer, the DUP 5EN delivers a wide frequency response of 130 Hz to 17,000 Hz. With a sensitivity of 92 dB and a maximum SPL of 100 dB at 1 meter, it ensures clear and powerful sound across most indoor spaces. Its 180° coverage angle provides uniform sound distribution, making it suitable for large rooms, corridors, or open areas where consistent audio coverage is essential.
The speaker offers selectable power options (6 W, 3 W, 1.5 W) at 100 V, allowing flexible integration into 70 V or 100 V constant voltage systems. Its compact, lightweight design and simple wall-mounting options enable quick and easy installation, while the durable ABS plastic body and steel grille finished in white RAL 9016 provide protection and a clean, modern appearance. Certified to EN54-24 for fire alarm and public address systems, the DUP 5EN ensures dependable performance and clear communication in any setting, whether for general audio reinforcement or emergency alerts.
Product Specifications:
Cabinet/Case Material: ABS
Grille: Steel
Color: White (RAL 9016)
Frequency Response (-10 dB): 130 Hz – 17,000 Hz
Maximum SPL @ 1 m: 100 dB
Maximum SPL @ 4 m: 88 dB
Coverage Angle: 180°
System Sensitivity: 92 dB
System Sensitivity (1 W @ 4 m): 80 dB
Power Section
Power Handling: 6 W
Peak Power Handling: 24 W (Peak)
Protections: Thermal fuse
Recommended Amplifiers: DXT 3000, DXT 4000, DXT 7000
Transducers
Type: Full-range
Size: 1 × 5.5"
Input/Output Section:
Input Connectors: Ceramic screw terminals
Output Connectors: Ceramic screw terminals
Constant Voltage Transformer: 100 V
Power Selections:
6 W – 1667 Ω
3 W – 3333 Ω
1.5 W – 6667 Ω
Standard Compliance:
Safety Agency: CE compliant
EN54-24 Certified: Yes
CPR Number: 0068-CPPR-085/2017
Product Dimensions (L × W × H): 3.15 in × 10.51 in × 6.54 in
Product Weight: 2.54 lbs.
Shipping Dimensions (L × W × H): 6.69 in × 11.02 in × 3.54 in
Shipping Weight: 3.00 lbs.
