Description
The RCF KPS 168D is a professional 8-channel amplifier delivering a total output power of 1280 W, designed for demanding audio installations that require flexibility, reliability, and advanced system control. Its Class-D amplification technology ensures efficient performance while maintaining high audio quality for professional applications.
The amplifier features integrated DSP for complete and precise signal processing, with easy configuration through RCF RDSpace software. It also includes a library of RCF loudspeaker presets, simplifying system setup and helping achieve optimal audio performance across different installation environments.
With native Ethernet connectivity, the KPS 168D is ideal for distributed audio systems with independent zone control. The integrated wireless access point allows direct connection with mobile devices, while the built-in Audinate Dante AoIP network interface enables the distribution of 4 digital audio channels for advanced networked audio applications.
Product Specifications:
Amplifier Class: D
Output Power: 8 × 160 W @ 4 ohm, 8 × 160 W @ 8 ohm, 4 × 320 W @ 4 ohm (bridge), 4 × 320 W @ 8 ohms (bridge)
Output Power @ 100 V: 4 × 320 W
Output Power @ 70 V: 4 × 320 W
Frequency Response (-3dB): 20 Hz – 20000 Hz
SNR Analog Inputs (A weighted): >106 dB
SNR Digital Inputs (A weighted): >106 dB
Distortion (THD+N) 20 Hz – 20000 Hz, 160 W @ 8 ohm: <0.05 %
Total Number of Inputs: 13
Mic+Line Inputs: 8
Mic+Line Connectors: Euroblock, RCA
Digital Inputs: 5
Digital Connectors: RCA, RJ45
Digital Type: Dante, S/PDIF
General Purpose Inputs (GPI): 5
Programmable GPI: Yes
Signal Output Number: 1
Signal Output Connectors: RCA
Power Output Connectors: Euroblock
General Purpose Outputs (GPO): 5
Programmable GPO: Yes
DSP: Yes Configuration and Control
Configuration: PC Software
Network: Ethernet
RCF Speakers Presets: Yes
Priority: Yes
Protocols for System Integration: AMX, CRESTRON, Q-SYS, Symmetrix
Cooling: Forced
Short Circuit: Yes
Thermal: Yes
DC: Yes
Fuses: Yes
VHF (Very High Frequencies): Yes
Operating Voltage: 90–240 V~ 50/60 Hz
Power Consumption (MAX): 300 W
Safety Agency: CE Compliant, UL62368-1
Cabinet Material: Metal
Color: Black
Rack Mounting: 19 inches, 1U
Product Dimensions (H×L×D): 1.73 × 18.98 × 12.56 inches
Product Weight: 8.38 lbs.
Shipping Dimensions (H×L×D): 3.15 × 14.17 × 22.83 inches
Shipping Weight: 11.68 lbs.
