Description
The RCF KPS 802 is a professional 2-channel amplifier delivering a total output power of 1600 W, designed for demanding audio installations where flexibility, reliability, and advanced control are required. Its Class-D amplification technology ensures efficient operation and dependable performance for professional sound applications.
The amplifier features integrated DSP for precise and complete signal processing, allowing users to configure and optimize the system easily through RCF RDSpace software. In addition, the built-in library of RCF loudspeaker presets simplifies setup and helps achieve optimal audio performance in various installation environments.
With native Ethernet connectivity, the KPS 802 is ideal for distributed audio systems with independent zone control. The integrated wireless access point also allows direct connection with mobile devices, making system management and configuration more convenient and accessible.
Product Specifications:
Amplifier Class: D
Output Power: 2 × 1200 W @ 2.7 ohm
2 × 800 W @ 4 ohm
2 × 400 W @ 8 ohm
1 × 1600 W @ 4 ohm (bridge)
1 × 1600 W @ 8 ohms (bridge)
Output Power @ 100 V: 1 × 1600 W
Output Power @ 70 V: 1 × 1200 W
Frequency Response (-3dB): 20 Hz – 20000 Hz
SNR Analog Inputs (A weighted): >108 dB
SNR Digital Inputs (A weighted): >108 dB
Distortion (THD+N) 20 Hz – 20000 Hz, 400 W @ 8 ohm: <0.05 %
Total Number of Inputs: 5
Mic+Line Inputs: 4
Mic+Line Connectors: Euroblock, RCA
Digital Inputs: 1
Digital Connectors: RCA
Digital Type: S/PDIF
General Purpose Inputs (GPI): 5
Programmable GPI: Yes
Signal Output Number: 1
Signal Output Connectors: RCA
Power Output Connectors: Euroblock
General Purpose Outputs (GPO): 5
Programmable GPO: Yes
DSP: Yes
Configuration: PC Software
Network: Ethernet
RCF Speakers Presets: Yes
Priority: Yes
Protocols for System Integration: AMX, CRESTRON, Q-SYS, Control
Cooling: Forced
Short Circuit: Yes
Thermal: Yes
DC: Yes
Fuses: Yes
VHF (Very High Frequencies): Yes
Power Requirement Operating Voltage: 90–240 V~ 50/60 Hz
Power Consumption (MAX): 350 W
Safety Agency: CE Compliant, UL62368-1
Cabinet Material: Metal
Color: Black
Rack Mounting: 19 inches, 2U
Product Dimensions (H×L×D): 3.46 × 19.02 × 12.6 inches
Product Weight: 13.01 lbs.
Shipping Dimensions (H×L×D): 7.48 × 15.35 × 22.05 inches
Shipping Weight: 17.42 lbs.
