Description
The RCF KPS 802D is a professional 2-channel amplifier delivering a total output power of 1600 W, designed for demanding audio installations that require flexibility, reliability, and advanced control capabilities. Its Class-D amplification technology provides efficient and consistent performance for professional audio applications.
The amplifier includes integrated DSP for accurate and complete signal processing, with simple and intuitive configuration through RCF RDSpace software. A built-in library of RCF loudspeaker presets further simplifies setup and helps ensure optimal audio performance across different installation environments.
With native Ethernet connectivity, the KPS 802D is ideal for distributed systems with independent zone control. The integrated wireless access point allows direct connection with mobile devices, while the built-in Audinate Dante AoIP network interface enables the distribution of 4 digital audio channels for advanced networked audio integration.
Product Specifications:
Amplifier Class: D
Output Power: 2 × 1200 W @ 2.7 ohm
2 × 800 W @ 4 ohm
2 × 400 W @ 8 ohm
1 × 1600 W @ 4 ohm (bridge)
1 × 1600 W @ 8 ohm (bridge)
Output Power @ 100 V: 1 × 1600 W
Output Power @ 70 V: 1 × 1200 W
Frequency Response (-3dB): 20 Hz – 20000 Hz
SNR Analog Inputs (A weighted): >108 dB
SNR Digital Inputs (A weighted): >108 dB
Distortion (THD+N) 20 Hz – 20000 Hz, 400 W @ 8 ohm: <0.05 %
Total Number of Inputs: 9
Mic+Line Inputs: 4
Mic+Line Connectors: Euroblock, RCA
Digital Inputs: 5
Digital Connectors: RCA, RJ45
Digital Type: Dante, S/PDIF
General Purpose Inputs (GPI): 5
Programmable GPI: Yes
Signal Output Number: 1
Signal Output Connectors: RCA
Power Output Connectors: Euroblock
General Purpose Outputs (GPO): 5
Programmable GPO: Yes
DSP: Yes
Cooling: Forced
Short Circuit: Yes
Thermal: Yes
DC: Yes
Fuses: Yes
VHF (Very High Frequencies): Yes
Operating Voltage: 90–240 V~ 50/60 Hz
Power Consumption (MAX): 350 W
Safety Agency: CE Compliant, UL62368-1
Cabinet Material: Metal
Color: Black
Rack Mounting: 19 inches, 2U
Product Dimensions (H×L×D): 3.46 × 19.02 × 12.6 inches
Product Weight: 13.01 lbs.
Shipping Dimensions (H×L×D): 7.48 × 15.35 × 22.05 inches
Shipping Weight: 17.42 lbs.
