Description
The RCF PL 50EN is a high-performance, passive 2-way ceiling loudspeaker designed for recessed installation in ceilings and panels. It is ideal for both alarm messaging and general sound reinforcement in commercial and industrial environments. Built with durability and safety in mind, this model is engineered to maintain reliable operation even under extreme conditions, making it particularly suitable for fire safety and emergency communication systems.
Exceptional Audio Performance:
Featuring a 5-inch full-range transducer, the PL 50EN delivers a wide frequency response from 130 Hz to 15,000 Hz, ensuring clear and accurate reproduction of both speech and background music. With a sensitivity of 92 dB and a maximum SPL of 100 dB at 1 meter, it provides strong output levels suitable for medium-sized areas.
Its 160° coverage angle ensures broad and even sound distribution, effectively covering hallways, lobbies, offices, and public spaces without dead zones.
Flexible Power Configuration:
For integration into constant-voltage audio systems, the PL 50EN includes selectable power taps at 6 W, 3 W, 1.5 W, and 0.75 W (100V line). The ceramic terminal blocks support flameproof and secure connections for both input and output wiring, making it fully compatible with fire alarm and emergency evacuation systems. A built-in thermal fuse provides automatic protection against overheating, ensuring continued safety during critical events.
Reliable Construction for Safety:
The loudspeaker is constructed with a flameproof steel back can, enhancing safety and environmental durability. Its steel grille and frame add structural strength, while the white RAL 9016 finish blends discreetly into most ceiling designs.
The PL 50EN is EN54-24 certified, guaranteeing full compliance with modern fire safety and evacuation standards, and is CE compliant, ensuring adherence to essential safety and quality requirements.
Easy Installation:
Designed for convenient recessed mounting, the PL 50EN features a recessed depth of 4.92 inches and an overall diameter of 7.13 inches, making it compatible with standard ceiling cavities. Weighing only 2.98 lbs. it is lightweight and easy to handle during installation.
Whether used for fire alarm announcements, background music distribution, or general public address applications, the RCF PL 50EN delivers consistent, high-quality performance in demanding environments.
Product Specifications:
Cabinet Material: Metal
Hardware: Steel back cover
Grille: Steel
Color: White (RAL 9016)
Frequency Response (-10 dB): 130 Hz – 15,000 Hz
Max SPL @ 1 m: 100 dB
Max SPL @ 4 m: 88 dB
Coverage Angle: 160°
Sensitivity: 92 dB
Sensitivity (1W @ 4 m): 80 dB
Power Section:
Amplification: Full-range
Rated Power Handling: 6 W
Peak Power Handling: 24 W
Protections: Thermal fuse
Recommended Amplifiers: DXT 3000, DXT 4000, DXT 7000
Transducers:
Full-Range Driver: 1 × 5"
Input / Output Section:
Input Connectors: Ceramic screw terminals
Output Connectors: Ceramic screw terminals
Constant Voltage: 100 V
Power Taps:
6 W – 1667 Ω
3 W – 3333 Ω
1.5 W – 6667 Ω
0.75 W – 13333 Ω
Standards & Certifications:
Compliance: CE compliant
EN54-24 Certification: Yes
CPR Number: 0068-CPR-051/2017
Product Weight: 2.98 lbs.
Product Dimensions (L × W × H): 5.63 in × 7.13 in × 5.63 in
Shipping Weight: 3.10 lbs.
Shipping Dimensions (L × W × H): 6.30 in × 7.48 in × 6.30 in
