Description
The RCF UP-2321 Power Amplifier - 320-Watt is equipped with a Microphone/Line main input via a removable connector, an XLR connector, or an RJ45 port. The amplifier also features an RCA Auxiliary input for music sources such as CD players and tuners. The amplifier output is available for either low impedance speakers or 100-70 constant voltage line. The Class D amplifier features a switching power supply. The UP 2321 is designed for the transmission of announcements and musical programs. It is ideal for use in restaurants, shops, supermarkets, hotels, offices, department stores, industrial systems and similar applications.
Product Specifications:
Power Output: 320 W RMS
Frequency Response: 50 Hz to 15 kHz
Presence Frequency Bands: 2.15 kHz, +10 dB
High-Pass Filter: 150 Hz
Output Impedance: 4 ohms
Output Voltage: 70 V (31 ohms) / 100 V (62 ohms)
Operating Voltage: 115-230 V, 50/60 Hz
Power Consumption: 600 W
Controls: Master volume, Treble, Bass, Gain, Presence
Protections: Overload, short circuit, thermal
Dimensions: 3.4 x 17.4 x 8.6" (88 x 444 x 220 cm)
Weight: 12.2 lb (5.5 kg)
Package Weight: 14 lbs
Package Dimension: 20, 13, 8”
