RF Venue 4-Zone Antenna Combiner for Wireless Microphone Receivers
RF Venue 4-Zone Antenna Combiner for Wireless Microphone Receivers
RF Venue 4-Zone Antenna Combiner for Wireless Microphone Receivers
RF Venue 4-Zone Antenna Combiner for Wireless Microphone Receivers
Roll over image to zoom in Click on image to zoom
RF Venue 4-Zone Antenna Combiner for Wireless Microphone ReceiversRF Venue 4-Zone Antenna Combiner for Wireless Microphone ReceiversRF Venue 4-Zone Antenna Combiner for Wireless Microphone ReceiversRF Venue 4-Zone Antenna Combiner for Wireless Microphone Receivers

RF Venue 4-Zone Antenna Combiner for Wireless Microphone Receivers
Save $284.70
RF Venue
No reviews
SKU H-RFVE-4ZONE UPC 459225904370
Price:
$949.00 $1,233.70
Earn 474500 points (worth $47.45)
Price Match Guaranteed if we lower the price within 30 days of your purchase, we’ll issue a store credit for the difference. Shop confidently knowing you’ll always get our best price. Free 2nd Day Air Delivery We offer Free 2nd Day Air on most items! Some exceptions apply, including oversized, truss, and stage products. Reward Points Earn 5% Back in HDJ Points on every purchase — use your points toward future gear purchases with us.

2 Day Shipping is Free or heavily discounted on most items! Make sure you select 2nd Day Shipping. We want to ship your order the fastest way possible.

Signature required for all deliveries/shipments for your security.

Call us for package deal pricing, we can help.

We price match competitor advertised prices.

Our online prices are always honored instore guaranteed.

Hassle Free Financing Available

Get the gear you need now with Financing options. As an artist or sound professional your business needs high speakers, lighting and cases to do your job, be professional and competitive.

Choose Shop Pay or After Pay in checkout for instant financing. We also offer Accima, Synchrony, Progressive or Snap financing just give us a call 1-800-700-4542.

Description

The RF Venue 4 Zone is an antenna combiner designed to simplify RF signal management for multi-zone wireless microphone systems. It combines up to four separate pairs of diversity antenna connections into a single A and B output, making it ideal for multi-purpose venues, indoor/outdoor installations, main stages, and breakout rooms. Compatible with all major wireless microphone brands, it operates across a wide 470–960 MHz frequency range.

The 4 Zone provides individual RF signal attenuation control for each channel, allowing precise adjustment of coverage areas with attenuation settings from 0 to -31 dB in 1 dB increments. Selectable On/Off inputs make it easy to activate or deactivate coverage zones, helping streamline setup and operation for roaming wireless microphone transmitters.

For enhanced system flexibility, the 4 Zone can supply selectable 12 VDC power to active antennas or in-line amplifiers, making it well suited for long cable runs. Its intuitive design reduces the complexity of multi-zone antenna distribution while delivering reliable wireless microphone performance in professional audio, broadcast, and live event applications.

What's Included:

RF Venue 4 Zone - Antenna Combiner for Wireless Mic Receivers (470 - 960 MHz)

AC Power Cable

2 x BNC to BNC Coaxial Cables (8")

Product Type: Antenna combiner for wireless microphone receivers

Coverage Zones: Up to 4 zones

Frequency Range: 470–960 MHz

Compatibility: Works with all wireless microphone brands

Antenna Inputs: 4 pairs of diversity antenna inputs

Antenna Outputs: 1 × A output, 1 × B output

RF Attenuation: 0 to -31 dB

Attenuation Steps: 1 dB increments

Zone Control: Selectable On/Off inputs per zone

DC Power Output: Selectable 12 VDC for active antennas and in-line amplifiers

Weight: 4.0 lb (1.8 kg)

Dimensions (L × W × H): 19 × 7.5 × 1.75 in
