Shure Ceiling 1, Ceiling Array Microphone with Audio Fencing

The Shure Ceiling 1 features a 100-microphone array with wide, medium, and narrow pickup beam options to configure the device for the size of your room. Voice-activity detection and automatic tracking of the person speaking ensure intelligible speech capture. Automatic gain control adjusts the volume of people close to and far from the microphones, while adaptive echo cancellation, dereverberation, and background noise reduction ensure comfortable communication, free from distracting sounds.

Part of the Stem Audio ecosystem for conference rooms, the Stem Ceiling is an elegant, beamforming microphone array that easily mounts on the ceiling of your conference room.

Offering clear and highly intelligible speech capture with state-of-the-art sound quality that enhance the conferencing experience for all participants. This device connects to your local network with PoE+ (Power over Ethernet) or to a computer in meeting rooms, collaboration areas, and huddle rooms.

Product Specification:

Includes: 24 inch enclosure, suspension mount, 12 ft USB Cable and 15 ft CAT6 cable

PC Connectors: 1 x USB Type-B

Microphones: 100 x Wide, Medium, Narrow Array

Echo Cancellation: > 40 dB, Conversion Speed 40 dB/Second

Noise Cancellation: > 15 dB

Frequency Response: 50 Hz to 16 KHz

Broadcast Level: 90 dB SPL at 1 kHz from 3.3' / 1 m, 5 W RMS

Cable Length:

Suspension Cable: 120" / 304.8 cm

Ethernet Cable: 15' / 4.6 m

USB Cable: 12' / 3.7 m

Dimensions:

Ceiling Microphone Diameter: 21.5" / 54.6 cm

Height at Edge: 0.5" / 1.8 cm

Height at Center: 1.75" / 4.4 cm

Ceiling Tile: 23.5 x 23.5 x 1.25" / 59.7 x 59.7 x 4.4 cm

Weight: Ceiling Microphone: 9 lb / 4.1 kg, Ceiling Tile: 7.5 lb / 3.4 kg

Package Weight: 18.745 lb

Box Dimensions: 24.8 x 24.1 x 4.9"
