Description
The Yamaha PA2030 is a compact, versatile power amplifier designed for commercial installations, offering reliable performance in a lightweight and easy-to-install package. Featuring a Lo-Z/Hi-Z switchable Class-D output, it delivers 30W per channel at 3Ω/4Ω or 60W at 70V/100V, ensuring clear and powerful sound across a variety of commercial spaces. Its frequency response and low distortion (THD+N ≤0.2%) guarantee high-fidelity audio from line inputs to speaker outputs.
Connectivity is simple and flexible, with multiple input options including a balanced XLR combo mic input, 3.5mm Euroblock mic input, stereo mini phone and RCA line inputs, and balanced/unbalanced line outputs. Speaker outputs are provided via barrier strips, supporting easy integration with a range of commercial speaker systems. Crosstalk is kept to a minimum (≤ -70dB), ensuring clean signal separation for a professional sound experience.
The PA2030 is designed for quick setup and straightforward operation, with conventional cooling and support for AC power from 100V to 240V at 50/60Hz. Compact and lightweight, it measures 11.4" × 8.5" × 2.1" and weighs only 4.0 lbs (1.8 kg), making it easy to install or pair with the MA2030 mixer amplifier for a complete audio solution. Its durable build, wide operating temperature range, and low power consumption of 30W at 1/8 max power further make it a reliable choice for commercial audio installations.
Product Specifications:
Speaker Power Output (1% THD+N, 20ms burst): 3Ω/4Ω: 30W x 2; 70V/100V: 60W x 1
Amplifier Type (Output Circuitry): Class D
Input Level (Stereo Input) Unbalanced Sensitivity / Nominal: -10.0 dBV; Max before clip: +10.0 dBV
Input Level (Stereo Input) Balanced Sensitivity / Nominal: +4.0 dBu; Max before clip: +24.0 dBu
Output Level (Line Out) Nominal: -10.0 dBV
THD+N: Stereo in to Speaker out; 1kHz, 3Ω/4Ω, 1W: ≤ 0.1%; Stereo in to Speaker out; 1kHz, 70V/100V,
1W: ≤ 0.2%
Frequency Response: Stereo in to Line out; 20Hz to 20kHz: 0dB, -2.5dB, +1.0dB; Stereo in to Speaker
out; 50Hz to 20kHz, 1W, 3Ω/4Ω: 0dB, -3.0dB, +1.0dB; Stereo in to Speaker out; 90Hz to 20kHz, 1W,
70V/100V: 0dB, -3.0dB, +1.0dB
Crosstalk: Stereo in to another Stereo in ≤ -70dB
Connectors:
Mic Input: MIC IN 1 XLR combo jack, balanced
MIC IN 2: 3.5mm Euroblock 3-pin, balanced
Stereo Input: ST IN 1 Stereo mini phone (3.5mm), unbalanced
ST IN 2 / ST IN 3: Stereo RCA pin, unbalanced
LINE IN: Stereo RCA pin (unbalanced), 3.5mm Euroblock 3-pin x 2 (balanced)
Speaker Output: Barrier strip x 2 pairs
Line Out: Stereo RCA pin, unbalanced
Cooling: Conventional cooling, bottom to up airflow
AC Power Requirement: 100V / 120V / 230V–240V; 50Hz/60Hz
Power Consumption: 1/8 max power, 3Ω, AC100V, pink noise at all channels: 30W
Operating Temperature: 0°C to +40°C
Storage Temperature: -20°C to +60°C
Product Weight: 4.0 lbs / 1.8 kg
Product Dimensions (L × W × H): 11.4" × 8.5" × 2.1"
