Description
The Yorkville Sound SA115S powered subwoofer is the companion piece to the SA102 full range speaker. Together, these components create a smaller, lighter and more portable Synergy Array system, without sacrificing the impressive bass Synergy is known for. The Tom Danley patented 15" tapped-horn design allows for the SA115S to deliver an astonishing 9000 watts (peak), and 4500 watts (program) in a compact cabinet.
Product Specification:
System Type: Active Subwoofer
Active or Passive: Active
Power Rating (Watts): 4500 Watts Program (9000 Watts Peak)
Measured Max SPL (C-Weighted, Max Hold): 129dB Cont. 135 dB Peak
Frequency Response (Hz +/- 3dB): 31Hz-100Hz
Crossover Frequency (Hz): 100 Hz lowpass
Cabinet Configuration: Tapped Horn
Driver Configuration: 1x15" LF woofer
LF Driver(s): 15" Neodymium with 4.5" Voice Coil
LF Power Rating(Watts): 4500 Watts Program (9000 Watts Peak)
LF Impedance (Ohms): 4 ohm Load
LF Protection: Excursion, Voice Coil Thermal (RMS)
LF Amplifier Type: Class D
Cooling Scheme: Convection
Power Cable: Removable Locking Powercon True Input and Loop Thru Output
Power Switch: Yes
Inputs: 1 XLR with 2x XLR Parallel out, Impedance 35k ohms
Input Sensitivity (Vrms Sine): Line in 1.4 at center, 0.56 at max
Level Controls: Volume, -∞,0dB,8dB (Min, Top, Max)
EQ Controls: Thermal Limiter Advance for power consumption management
Limiter: Excursion, Thermal (RMS), Clipping
LED Indicators: Power, Excursion Limit, Thermal (RMS) Limit, Input Clip, Activity
Enclosure Materials: Multiply 15mm Birch Plywood
Stacking Feature: Interlocking Rubber Feet (Sides)
Covering / Finish: Paint
Dimensions (DWH xbackW, inches): 36.625 (including Casters) x 17.750 x 35.250
Dimensions (DWH xbackW, cm): 93 x 45 x 82
Weight (lbs/kg): 165/74.9
