Description
The DiGiCo X-Q326-W-ST-EX-ULT is a high-performance Quantum Series digital mixing console built for touring, broadcast, theater, and live production. Powered by DiGiCo's seventh-generation FPGA processing engine, it delivers exceptional sound quality, ultra-low latency, and remarkable processing power. The compact design provides a fast and intuitive workflow without compromising professional capabilities. Engineers benefit from responsive control and extensive onboard processing. It is designed to perform in the most demanding production environments.
Ultimate Stadius Audio Quality
Ultimate Stadius technology provides premium 32-bit microphone preamps and converters for outstanding analog-to-digital and digital-to-analog performance. The enhanced conversion delivers greater dynamic range, improved detail, and lower noise across every channel. Combined with Quantum processing, it produces exceptionally transparent and accurate sound. Every source maintains its natural character from input to output. This makes the console ideal for high-end professional productions.
Waves SoundGrid & ST Connectivity
Integrated Waves SoundGrid enables seamless use of professional Waves plugins with extremely low latency. The Standard (ST) Optocore connector provides secure fiber networking for long-distance digital audio transport between stage and front of house. ST fiber connections are widely used in touring systems and permanent installations for dependable performance. Together, these technologies provide powerful processing and reliable connectivity. They create a flexible solution for complex live productions.
Fast and Efficient Workflow
The Quantum 326 features 26 touch-sensitive motorized faders, dual 17-inch high-resolution multi-touch displays, and 51 TFT channel displays. Engineers can quickly access routing, processing, snapshots, and monitoring functions with minimal navigation. The floating chassis provides excellent ergonomics during long productions. Clear visual feedback speeds operation in demanding environments. Every control is designed to maximize workflow efficiency.
Powerful Built-In Processing
Supporting up to 128 input channels, 64 fully processed buses, and a 24×24 matrix, the console easily handles complex productions. Built-in Mustard Processing, Spice Rack FPGA plugins, Nodal Processing, dynamic EQ, and premium internal effects provide extensive creative flexibility. The Quantum engine maintains smooth operation under heavy processing loads. Engineers can create sophisticated mixes without relying on external hardware. This delivers maximum performance for every production.
Built for Professional Applications
The X-Q326-W-ST-EX-ULT is designed for touring companies, rental providers, broadcast facilities, theaters, and houses of worship. Its rugged construction, advanced networking, and Ultimate Stadius technology ensure dependable operation show after show. Combined with Waves SoundGrid and Standard ST fiber connectivity, it integrates seamlessly into professional Optocore systems. The result is a complete flagship mixing solution for modern audio engineers.
What’s in the Box:
- SD ST Rack x 1 (56 Mic In x 40 Out x 16 AES-O)
- Ultimate Stadius' 32-Bit Mic Pre Amp & 32-Bit Output Package
- Connections: MADI x 6, Optics x 1
- Internal Waves Card
- UB-MADI, DMI Port x 2
- Connectors: BNC, ST
Product Specifications:
Connector: Standard (ST) Connector
Integrated Networking: Waves SoundGrid
Local I/O: Ultimate Stadius 32-bit Local I/O
Faders: 26 × 100 mm Touch-Sensitive Motorized
Display Screens: Dual 17" High-Brightness LCD Touchscreens
Input Channels: 128
Aux/Group Busses: Up to 64 (Mono, Stereo, LCR, LCRS, 5.1)
Matrix: 24 × 24 with Full Processing
Control Groups: Up to 24
Internal Effects: Up to 24 Stereo FX Engines
Spice Rack: 8 Mono / 4 Stereo Rack Slots
Mustard Processing: 36 Processing Strips
Nodal Processing: 64 Nodal Processors
Mic/Line Converters: 32-bit
MADI Interface: 6 × 48 kHz or 3 × 96 kHz (BNC)
Optocore Interface: Optional Dual Loop
DMI Slots: 2 × DiGiCo Multichannel Interface
Sampling Rates: 48 kHz / 96 kHz
GPI/GPO: 16
Waves Support: Optional
External Sync: Word Clock, AES, MADI, Optocore
Frequency Response: ±0.15 dB (20 Hz–20 kHz)
THD: <0.002% @ Unity Gain
Channel Separation: Better Than 120 dB
Residual Output Noise: <100 dBu
Microphone Input Noise: Better Than -128 dB EIN
Maximum Input Level: +22 dBu
Maximum Output Level: +22 dBu
Processing Delay: 1 ms Typical @ 96 kHz
Internal Processing: Up to 40-bit Floating Point
A/D & D/A Conversion: 32-bit
Input Gain: -20 dB to +60 Db
Digital Trim (Input): -40 dB to +40 dB
Output Trim: -20 dB to +60 dB
Channel Delay: Up to 1.3 Seconds
Output Delay: Up to 1.3 Seconds
HPF/LPF: 20 Hz–20 kHz, 24 dB/Octave
Input EQ: 4-Band Parametric/Dynamic EQ
Output EQ: 8-Band Parametric/Dynamic EQ
EQ Gain: ±18 dB
EQ Frequency Range: 20 Hz–20 kHz
Dynamic EQ: Supported
Compressor Types: Single-Band & 3-Band Multiband
Gate/Ducker: Yes
De-Esser: Yes
DiGiTuBe Processing: Drive & Bias Controls
Insert Points: Dual (Pre & Post EQ/Dynamics)
Fader Level: ∞ to +10 dB
Mustard Processing: Tube & Amp Emulation, Vintage Compressors, Optical Compressor, FET Limiter
Power Requirements: 100–240 VAC, 50/60 Hz, 295 VA
Product Weight: 114.6 lb
Product Weight (With Flight Case): 330.7 lb
Product Dimensions (L × W × H): 44.3" × 31.7" × 19.0"
Flight Case Dimensions (L × W × H): 49.3" × 25.4" × 45.3"
