Description
The DiGiCo X-Q326-W-WS-OP combines Quantum FPGA processing with the Ultimate Stadius audio platform to deliver exceptional sound quality and ultra-low latency. Designed for touring, broadcast, theater, and live production, it provides the processing power required for today's demanding applications. The compact control surface offers an intuitive workflow while maintaining flagship-level performance. Engineers benefit from fast operation and extensive onboard processing. It is built to perform reliably in professional environments.
Waves SoundGrid Integration
The integrated Waves SoundGrid interface allows direct connection to a Waves SuperRack SoundGrid system for real-time plugin processing. Engineers can use professional Waves EQs, compressors, reverbs, and dynamic processors with extremely low latency. Plugin parameters can be controlled directly from the console, simplifying live operation. This integration reduces external hardware while delivering studio-quality sound in live environments. It is ideal for advanced production workflows.
OpticalCON Optocore Connectivity
This model includes a rugged OpticalCON Optocore connector for secure fiber networking between consoles, stage racks, and other compatible devices. The locking OpticalCON connection protects the fiber cable while providing stable, interference-free signal transmission over long distances. It is well suited for touring systems, festivals, stadiums, and broadcast facilities. The reliable connection ensures consistent communication throughout every production. It is trusted by professionals worldwide.
Fast and Efficient Workflow
The Quantum 326 features 26 touch-sensitive motorized faders, dual 17-inch high-resolution touchscreens, and 51 individual TFT channel displays. Engineers can quickly access routing, snapshots, processing, and monitoring functions through an intuitive interface. The floating chassis provides excellent ergonomics during extended mixing sessions. Clear visual feedback improves speed and accuracy during live events. Every control is designed to maximize efficiency.
Powerful Built-In Processing
Supporting up to 128 input channels, 64 fully processed buses, and a 24×24 matrix, the console easily manages complex productions. Built-in Mustard Processing, Spice Rack FPGA plugins, Nodal Processing, True Solo, and premium internal effects provide exceptional creative flexibility. Extensive onboard processing minimizes the need for external equipment. The Quantum engine maintains smooth performance under demanding workloads. This delivers outstanding results for every production.
W Package Advantages
The W Package includes factory-integrated Waves SoundGrid networking, enabling seamless operation with Waves SuperRack, SoundGrid servers, and certified network infrastructure. This package is ideal for engineers who rely on live plugin processing and advanced digital networking. Combined with Ultimate Stadius technology and OpticalCON Optocore connectivity, it provides a complete professional solution for high-end live sound applications. It is designed for maximum flexibility and long-term reliability.
What’s in the Box:
- MADI x 6, Optics x 1
- Internal Waves Card, UB-MADI
- DMI Port x 2
- Connectors: BNC, HMA
Product Specifications:
Connector: OpticalCON Optocore Connector.
Integrated Networking: Waves SoundGrid
Package: W Package (Integrated Waves SoundGrid)
Faders: 26 × 100 mm Touch-Sensitive Motorized
Display Screens: Dual 17" High-Brightness LCD Touchscreens
Input Channels: 128
Aux/Group Busses: Up to 64 (Mono, Stereo, LCR, LCRS, 5.1)
Matrix: 24 × 24 with Full Processing
Control Groups: Up to 24
Internal Effects: Up to 24 Stereo FX Engines
Spice Rack: 8 Mono / 4 Stereo Rack Slots
Mustard Processing: 36 Processing Strips
Nodal Processing: 64 Nodal Processors
Mic/Line Converters: 32-bit
MADI Interface: 6 × 48 kHz or 3 × 96 kHz (BNC)
Optocore Interface: Optional Dual Loop
DMI Slots: 2 × DiGiCo Multichannel Interface
Sampling Rates: 48 kHz / 96 kHz
GPI/GPO: 16
Waves Support: Optional
External Sync: Word Clock, AES, MADI, Optocore
Frequency Response: ±0.15 dB (20 Hz–20 kHz)
THD: <0.002% @ Unity Gain
Channel Separation: Better Than 120 dB
Residual Output Noise: <100 dBu
Microphone Input Noise: Better Than -128 dB EIN
Maximum Input Level: +22 dBu
Maximum Output Level: +22 dBu
Processing Delay: 1 ms Typical @ 96 kHz
Internal Processing: Up to 40-bit Floating Point
A/D & D/A Conversion: 32-bit
Input Gain: -20 dB to +60 Db
Digital Trim (Input): -40 dB to +40 dB
Output Trim: -20 dB to +60 dB
Channel Delay: Up to 1.3 Seconds
Output Delay: Up to 1.3 Seconds
HPF/LPF: 20 Hz–20 kHz, 24 dB/Octave
Input EQ: 4-Band Parametric/Dynamic EQ
Output EQ: 8-Band Parametric/Dynamic EQ
EQ Gain: ±18 dB
EQ Frequency Range: 20 Hz–20 kHz
Dynamic EQ: Supported
Compressor Types: Single-Band & 3-Band Multiband
Gate/Ducker: Yes
De-Esser: Yes
DiGiTuBe Processing: Drive & Bias Controls
Insert Points: Dual (Pre & Post EQ/Dynamics)
Fader Level: ∞ to +10 dB
Mustard Processing: Tube & Amp Emulation, Vintage Compressors, Optical Compressor, FET Limiter
Power Requirements: 100–240 VAC, 50/60 Hz, 295 VA
Product Weight: 114.6 lb
Product Weight (With Flight Case): 330.7 lb
Product Dimensions (L × W × H): 44.3" × 31.7" × 19.0"
Flight Case Dimensions (L × W × H): 49.3" × 25.4" × 45.3"
