Description
The DiGiCo X-Q326-WS-ST combines the power of Quantum processing with a compact and highly efficient control surface. It delivers exceptional audio quality, fast response, and extensive processing capabilities for demanding live sound applications. The console supports large channel counts while maintaining smooth operation during complex productions. Its advanced architecture provides engineers with outstanding flexibility and reliability. This makes it an excellent choice for professional touring, broadcast, and installed audio systems.
Integrated Waves SoundGrid
Built-in Waves SoundGrid compatibility enables real-time plugin processing with extremely low latency. Engineers can use industry-leading Waves plugins for EQ, dynamics, reverbs, and mastering directly within their workflow. The system expands creative possibilities without placing additional load on the console's internal processing. It is ideal for concerts, houses of worship, broadcast, and theater productions. Waves integration delivers studio-quality sound in demanding live environments.
Standard (ST) Fiber Connectivity
This version includes the Standard (ST) fiber connector for seamless Optocore networking. The ST connection provides reliable long-distance audio transmission with minimal signal loss. It allows easy integration with DiGiCo racks and other compatible Optocore devices. Fiber connectivity improves system stability in large venues and touring applications. The result is dependable performance for mission-critical live productions.
Intuitive Control Surface
The X-Q326 features 26 touch-sensitive, motorized faders that provide smooth and accurate control. Dual 17-inch high-brightness multitouch displays offer quick access to channels, routing, and processing functions. Dedicated TFT channel displays keep essential information visible at all times. The ergonomic layout helps engineers work efficiently during fast-paced live events. Every control is designed for speed, accuracy, and confidence.
Flexible Mixing Performance
Supporting up to 128 input channels and extensive bus configurations, the console adapts easily to productions of every size. Engineers can configure auxes, groups, matrices, and control groups to match specific workflows. Powerful onboard processing eliminates the need for excessive external hardware. Flexible routing simplifies complex audio systems while maintaining excellent sound quality. The console is equally suited for concerts, festivals, theaters, and broadcast facilities.
Built for Professional Applications
Designed for professional audio engineers, the X-Q326 delivers dependable performance under demanding conditions. Its compact footprint makes transportation and installation easier without sacrificing processing power. Rugged construction ensures long-term durability for touring and fixed installations. Combined with Waves SoundGrid and ST fiber networking, it provides a complete mixing solution for modern productions. The Quantum 326 offers the performance, flexibility, and reliability expected from DiGiCo's flagship technology.
What’s in the Box:
- MADI x 6, Optics x 1
- UB-MADI
- DMI Port x 2
- Connectors: BNC, ST
Product Specifications:
Connector: Standard (ST) Connector
Integrated Networking: Waves SoundGrid
Local I/O: Ultimate Stadius 32-bit Local I/O
Faders: 26 × 100 mm Touch-Sensitive Motorized
Display Screens: Dual 17" High-Brightness LCD Touchscreens
Input Channels: 128
Aux/Group Busses: Up to 64 (Mono, Stereo, LCR, LCRS, 5.1)
Matrix: 24 × 24 with Full Processing
Control Groups: Up to 24
Internal Effects: Up to 24 Stereo FX Engines
Spice Rack: 8 Mono / 4 Stereo Rack Slots
Mustard Processing: 36 Processing Strips
Nodal Processing: 64 Nodal Processors
Mic/Line Converters: 32-bit
MADI Interface: 6 × 48 kHz or 3 × 96 kHz (BNC)
Optocore Interface: Optional Dual Loop
DMI Slots: 2 × DiGiCo Multichannel Interface
Sampling Rates: 48 kHz / 96 kHz
GPI/GPO: 16
Waves Support: Optional
External Sync: Word Clock, AES, MADI, Optocore
Frequency Response: ±0.15 dB (20 Hz–20 kHz)
THD: <0.002% @ Unity Gain
Channel Separation: Better Than 120 dB
Residual Output Noise: <100 dBu
Microphone Input Noise: Better Than -128 dB EIN
Maximum Input Level: +22 dBu
Maximum Output Level: +22 dBu
Processing Delay: 1 ms Typical @ 96 kHz
Internal Processing: Up to 40-bit Floating Point
A/D & D/A Conversion: 32-bit
Input Gain: -20 dB to +60 Db
Digital Trim (Input): -40 dB to +40 dB
Output Trim: -20 dB to +60 dB
Channel Delay: Up to 1.3 Seconds
Output Delay: Up to 1.3 Seconds
HPF/LPF: 20 Hz–20 kHz, 24 dB/Octave
Input EQ: 4-Band Parametric/Dynamic EQ
Output EQ: 8-Band Parametric/Dynamic EQ
EQ Gain: ±18 dB
EQ Frequency Range: 20 Hz–20 kHz
Dynamic EQ: Supported
Compressor Types: Single-Band & 3-Band Multiband
Gate/Ducker: Yes
De-Esser: Yes
DiGiTuBe Processing: Drive & Bias Controls
Insert Points: Dual (Pre & Post EQ/Dynamics)
Fader Level: ∞ to +10 dB
Mustard Processing: Tube & Amp Emulation, Vintage Compressors, Optical Compressor, FET Limiter
Power Requirements: 100–240 VAC, 50/60 Hz, 295 VA
Product Weight: 114.6 lb
Product Weight (With Flight Case): 330.7 lb
Product Dimensions (L × W × H): 44.3" × 31.7" × 19.0"
Flight Case Dimensions (L × W × H): 49.3" × 25.4" × 45.3"
