Description
The Universal Audio Apollo x16D Essentials+ is a professional Thunderbolt 3 audio interface designed for live sound venues, broadcast environments, and networked recording studios. Featuring 16-channel Dante connectivity and elite-class Apollo X conversion, it delivers exceptional audio quality with ultra-low-latency performance on Mac and Windows systems.
Powered by onboard HEXA Core DSP processing, the Apollo x16D allows engineers to run UAD plug-ins in real time while mixing and recording. The included Essentials+ bundle provides 32 premium UAD plug-ins, including classic compressors, EQs, reverbs, channel strips, Auto-Tune Realtime Access, and virtual instruments.
Built for scalable audio networking, the Apollo x16D supports Dante and AES67 workflows, allowing multiple units to be linked for large-scale productions. It also serves as a powerful immersive audio monitoring solution, supporting formats such as Dolby Atmos, Auro-3D, and Sony 360 Reality Audio for advanced studio mixing applications.
Product Specifications:
Channels of I/O: 18 Inputs / 20 Outputs, 16x16 Dante, 2x2 Digital.
Maximum Sample Rate: 192 kHz / 24-Bit.
Built-In DSP: 6x SHARC Processors.
Display: 18-Segment LED Metering.
Talkback Microphone: Built-In.
Monitor Outputs: 2x XLR Balanced Outputs.
Digital Audio I/O: AES3 Input and Output (XLR).
Host Connection: 2x USB-C (Thunderbolt 3).
Network Audio: 2x RJ45 Dante / AES67 Ports.
Word Clock I/O: BNC Input and Output.
Mute Function: Master Mute.
Frequency Response: 20 Hz – 20 kHz ±0.02 dB.
Maximum Output Level: +24 dBu / +10 dBV.
Output Impedance: 100 Ω.
Dynamic Range: 133 dBA.
THD+N: -129 dB (0.000037%).
Sample Rates: 44.1 kHz to 192 kHz.
Bit Depth: 24-Bit.
Latency: 1 ms @ 96 kHz (Thunderbolt).
Sync Sources: AES3, Dante, Internal, Word Clock.
OS Compatibility: macOS 10.15–14, Windows 10 or Later
Storage Requirement: 25 GB Minimum (100 GB Recommended).
Required Hardware: Thunderbolt 3 Cable.
Power Supply: 12V DC, 6A Adapter Included.
Power Consumption: 30 W Typical, 72 W Maximum.
Rack Size: 1U.
Operating Temperature: 32°F to 104°F (0°C to 40°C).
Product Weight: 15 lbs.
Product Dimensions (L x W x H): 19 x 13.5 x 1.74"
