Description
The Wharfedale Pro Delta-AX15B is a high-performance 15-inch active subwoofer designed to deliver powerful and precise low-frequency reproduction. Built with premium Baltic birch plywood and finished with a durable black paint coating, it offers exceptional durability and a sleek, professional appearance. The Delta-AX15B is engineered to complement Delta-AXF full-range loudspeakers, creating a seamless and balanced sound system for live events, installations, or portable setups. Its robust construction, efficient amplification, and deep bass response make the Delta-AX15B the perfect choice for enhancing low-end impact in demanding audio applications.
Birch Plywood
Delta-AXF models use premium Baltic birch plywood construction. Not only does this create a solid and durable cabinet, but it also contributes to the overall sound and character. Delta-AXF is also covered in our most durable and hard-wearing black paint finish. This ensures that a Delta-AXF will always look as good as the day you unboxed it.
Routed Logo
Delta-AX features a routed Wharfedale Pro logo. This fresh design helps to distinguish between the original Delta-A models and the updated Delta-AX models. It is also a logo to be proud of. A logo that lets your audience know that the sound of your even will be of the highest possible quality.
Full Range
The full range models (Delta-AX12 and Delta-AX15) use 2 x Class D amplifiers. These are specifically tuned and selected to be the perfect match for the HF and LF drivers inside.
With multiple analogue inputs, Delta-AX full range models are ready to connect to whatever signal source you have.
Subwoofers
The 15″ and 18″ active subwoofers use a single Class D amplifier to drive the LF transducer.
Inside the Delta-AX subwoofers is a highly efficient Class D amplifier.
The amplifier has been perfectly matched to the custom low frequency driver. This perfect combination leads to maximum efficiency and supreme output SPL.
Product Specifications:
System Type: Active 15” Subwoofer
Frequency Response (+/-3 dB): 42 Hz – 200 Hz
Calculated Maximum SPL @1 m: 130 dB
Low Frequency Transducer:
Size: 404 mm / 15″
Coil Size: 101.6 mm / 4″
Impedance: 8 Ω
Amplifiers:
Low-Frequency Power Amplifier RMS: 900 W (Class D)
High-Frequency Power Amplifier RMS: N/A
Amplifier Protection: Yes
Protection Features:
Power on Protection: Power switch on/off mute
Thermal Protection: Amplifier Shut Down. Auto Reset
Low Line Voltage Shut Down: 80% Nominal Line Voltage
Driver Protection: Yes
DC and Short Protection: Yes
Clip Limiter: Turns on Approx @ 900 W Output
Limiter Indicator: Red LED
Power Indicator: Green LED
Connectors:
Input Type: Balanced
Input Sensitivity:
Line: 0 dBu
Maximum Input Level: 22 dBu
Input Connector: TRS jack and socket XLR
Input Impedance:
Balanced: 20 KΩ
Unbalanced: 10 KΩ
Line Output Connector: Pin XLR Connector
Impedance Balanced:
Balanced: 200 Ω
Unbalanced: 100 Ω
Loop Gain: 0 dB
AC Power Details:
Power Supply: High Efficiency SMPS
AC Power Options: AC100-120 V~ / 220-240 V~, 50/60 Hz
Power on Indicator: Green LED
Enclosure:
Material and Finish: 15 mm Plywood
Colour Options: Black Paint
Product Weight: 33.1 kg / 72.82 lbs.
Product Dimensions: 24″ x 19″ x 19″
Shipping Weight: 36.7 kg / 80.74 lbs.
Shipping Dimensions: 21" x 26” x 21” inches.
